Icom IC-7760 Reference Manual page 11

REMOTE CONTROL
Remote control (CI-V) information
D Command table
Cmd� Sub cmd� Data
1A* 05 SET > Network
01 68 See p� 20�
01 69 See p� 20�
01 70 00 ~ 02
01 71 00/01
SET > Network > Different Segment Settings
01 72 See p� 20�
01 73 01 ~ 30
01 74 See p� 20�
01 75 00 ~ 02
SET > Network
01 76 See p� 18�
SET > Network > Remote Settings
01 77 00/01
01 78 00/01
01 79 00 00 01 ~
06 55 35
Description
Send/read the Primary DNS Server
(valid after restart) setting
L Valid when the DHCP (valid after
restart) is set to OFF�
Send/read the Secondary DNS
Server (valid after restart) setting
L Valid when the DHCP (valid after
restart) is set to OFF�
Send/read the Audio Buffer Size (via
LAN) (valid after restart) setting
(00=Small, 01=Mid, 02=Large)
L Valid when the controller and RF
deck are connected through a
network�
Send/read the Connection from
Different Segment (valid after
restart) setting
(00=OFF, 01=ON)
Send/read the IP Address (RF Deck)
(valid after restart) setting
L Valid when the Connection from
Different Segment (valid after
restart) is set to ON�
Send/read the Subnet Mask (RF
Deck) (valid after restart) setting
( 01=128�0�0�0 (1 bit) ~
30=255�255�255�252 (30 bit))
L Valid when the Connection from
Different Segment (valid after
restart) is set to ON�
Send/read the Default Gateway (RF
Deck) (valid after restart) setting
L Valid when the Connection from
Different Segment (valid after
restart) is set to ON�
L You cannot set the same address
as "IP Address (RF Deck)�"
Send/read the Audio Buffer Size
(valid after restart) setting
(00=Small, 01=Mid, 02=Large)
L Valid when the RF deck and the
controller are connected between
different segments�
Send/read the Network Name (valid
after restart) setting
(Up to 15 characters)
Send/read the Network Control
(valid after restart) setting
(00=OFF, 01=ON)
Send/read the Shutdown Function
setting
( 00=Only Shutdown,
01=Standby/Shutdown)
Send/read the Control Port (UDP)
(valid after restart) setting
(00 00 01=1 ~ 06 55 35=65535)
Cmd� Sub cmd� Data
1A* 05 01 80 00 00 01 ~
06 55 35
01 81 00 00 01 ~
06 55 35
01 82 00/01
01 83 See p� 18�
SET > Display
01 84 00 00 ~ 02 55 Send/read the LCD Backlight setting
01 85 00 00 ~ 02 55 Send/read the LED Bright setting
01 86 00/01
01 87 00 ~ 02
01 88 00 ~ 02
01 89 00/01
01 90 00/01
01 91 00/01
SET > Display > Filter Effect Screen
01 92 00/01
01 93 See p� 21�
SET > Display
01 94 00 ~ 03
01 95 00/01
01 96 00/01
01 97 00/01
01 98 See p� 18�
01 99 00/01
10
Description
Send/read the Serial Port (UDP)
(valid after restart) setting
(00 00 01=1 ~ 06 55 35=65535)
Send/read the Audio Port (UDP)
(valid after restart) setting
(00 00 01=1 ~ 06 55 35=65535)
Send/read the Internet Access Line
(valid after restart) setting
( 00=FTTH (Fiber To The Home),
01=ADSL/CATV)
Send/read the Network Radio Name
setting
(Up to 16 characters)
(00 00=0% ~ 02 55=100%)
(00 00=0% ~ 02 55=100%)
Send/read the Display Font setting
(00=Square, 01=Round)
Send/read the Meter Response
(Standard, Edgewise) setting
(00=Slow, 01=Mid, 02=Fast)
Send/read the Meter Type (Normal
Screen) setting
(00=Standard, 01=Edgewise, 02=Bar)
Send/read the Meter Type (Expand
Screen) setting
(00=Edgewise, 01=Bar)
Send/read the Meter Peak Hold
(Bar) setting
(00=OFF, 01=ON)
Send/read the Memory Name setting
(00=OFF, 01=ON)
Send/read the Waveform Type setting
(00=Line, 01=Fill)
Send/read the Waveform Color setting
Send/read the Screen Saver setting
( 00=OFF, 01=15 minutes,
02=30 minutes, 03=60 minutes)
Send/read the External Display setting
(00=OFF, 01=ON)
Send/read the External Display
Resolution setting
(00=800x480, 01=800x600)
Send/read the Opening Message
setting
(00=OFF, 01=ON)
Send/read the My Call setting
(Up to 10 characters)
Send/read the Display Language
setting
(00=English, 01=Japanese)
