REMOTE CONTROL
Remote control (CI-V) information
D Command table
Cmd� Sub cmd� Data
1A* 05 SET > Time Set
02 00 20 20 01 01
~
20 99 12 31
02 01 00 00 ~ 23
59
02 02 00/01
02 03 See p� 18�
02 04 See p� 21�
02 05 00/01
02 06 See p� 21�
02 07 See p� 18�
SCOPE SET: SCOPE > EXPD/SET (Touch for 1 second)
02 08 00/01
02 09 00 ~ 02
02 10 00 ~ 02
02 11 00/01
02 12 00 ~ 02
02 13 00/01
02 14 See p� 21�
02 15 See p� 21�
02 16 See p� 21�
02 17 00/01
02 18 00 ~ 02
02 19 00 ~ 02
02 20 00 ~ 09
02 21 00/01
Description
Date/Time >
Send/read the Date setting
( 20 20 01 01=2020/01/01 ~
20 99 12 31=2099/12/31)
Date/Time >
Send/read the Time setting
(00 00=00:00 ~ 23 59=23:59)
Date/Time >
Send/read the NTP Function setting
(00=OFF, 01=ON)
Date/Time >
Send/read the NTP Server Address
setting
(Up to 64 characters)
Send/read the UTC Offset setting
Send/read the CLOCK2 Function
setting
(00=OFF, 01=ON)
Send/read the CLOCK2 UTC Offset
setting
Send/read the CLOCK2 Name setting
(Up to 3 characters)
Send/read the Scope during Tx
(CENTER Type) setting
(00=OFF, 01=ON)
Send/read the Max Hold setting
(00=OFF, 01=10s Hold , 02=ON)
Send/read the CENTER Type
Display setting
( 00=Filter center,
01=Carrier point center,
02=Carrier point center (Abs� Freq�))
Send/read the Marker Position
(Fix Type/ SCROLL Type) setting
(00=Filter center, 01 Carrier point)
Send/read the Averaging setting
(00=OFF, 01=2, 02=3, 03=4)
Send/read the Waveform Type setting
(00=Fill, 01=Fill+Line)
Send/read the Waveform Color
(Current) setting
Send/read the Waveform Color
(Line) setting
Send/read the Waveform Color
(Max Hold) setting
Send/read the Waterfall Display setting
(00=OFF, 01=ON)
Send/read the Waterfall Speed setting
(00=Slow, 01=Mid, 02=Fast)
Send/read the Waterfall Size
(Expand Screen) setting
(00=Small, 01=Mid, 02=Large)
Send/read the Waterfall Peak Color
Level setting
(00=Grid 1 ~ 09=Grid 10)
Send/read the Waterfall Marker
Auto-hide setting
(00=OFF, 01=ON)
Cmd� Sub cmd� Data
1A* 05 02 22 00/01
02 23 00/01
SCOPE > EXPD/SET (Touch for 1 second) > Fixed Edges
02 24 See p� 21�
02 25 See p� 21�
02 26 See p� 21�
02 27 See p� 21�
02 28 See p� 21�
02 29 See p� 21�
02 30 See p� 21�
02 31 See p� 21�
02 32 See p� 21�
02 33 See p� 21�
02 34 See p� 21�
02 35 See p� 21�
02 36 See p� 21�
02 37 See p� 21�
02 38 See p� 21�
02 39 See p� 21�
02 40 See p� 21�
02 41 See p� 21�
02 42 See p� 21�
02 43 See p� 21�
02 44 See p� 21�
02 45 See p� 21�
02 46 See p� 21�
02 47 See p� 21�
02 48 See p� 21�
02 49 See p� 21�
11
Description
Send/read the Dual Scope Type
setting
(00=Over/Under, 01=Side by Side)
Send/read the Dual Scope Auto
Select setting
(00=OFF, 01=ON)
0�03 – 1�60 >
Send/read the No�1 setting
0�03 – 1�60 >
Send/read the No�2 setting
0�03 – 1�60 >
Send/read the No�3 setting
0�03 – 1�60 >
Send/read the No�4 setting
1�60 – 2�00 >
Send/read the No�1 setting
1�60 – 2�00 >
Send/read the No�2 setting
1�60 – 2�00 >
Send/read the No�3 setting
1�60 – 2�00 >
Send/read the No�4 setting
2�00 – 6�00 >
Send/read the No�1 setting
2�00 – 6�00 >
Send/read the No�2 setting
2�00 – 6�00 >
Send/read the No�3 setting
2�00 – 6�00 >
Send/read the No�4 setting
6�00 – 8�00 >
Send/read the No�1 setting
6�00 – 8�00 >
Send/read the No�2 setting
6�00 – 8�00 >
Send/read the No�3 setting
6�00 – 8�00 >
Send/read the No�4 setting
8�00 – 11�00 >
Send/read the No�1 setting
8�00 – 11�00 >
Send/read the No�2 setting
8�00 – 11�00 >
Send/read the No�3 setting
8�00 – 11�00 >
Send/read the No�4 setting
11�00 – 15�00 >
Send/read the No�1 setting
11�00 – 15�00 >
Send/read the No�2 setting
11�00 – 15�00 >
Send/read the No�3 setting
11�00 – 15�00 >
Send/read the No�4 setting
15�00 – 20�00 >
Send/read the No�1 setting
15�00 – 20�00 >
Send/read the No�2 setting
