CHAPTER 5
MAINTAINING THE INTERACTIVE FLAT PANEL
4. Continue until you've pressed all the targets.
The orientation window closes.
5. If orientation doesn't correct inaccurate touch, calibrate the interactive flat panel (see
Calibrating the interactive flat panel below).
Calibrating the interactive flat panel
Digital cameras in the corners of the interactive flat panel track the position of the pens, eraser and
your finger on the interactive surface, and then send the information to the SMART software on
connected computers, which interprets this information as mouse clicks, digital ink or an eraser in
the appropriate location. Calibration determines the position and angles of the cameras to
accurately identify the location of touches on the interactive flat panel.
IMPORTANT
If an error message appears while you calibrate the interactive flat panel, contact SMART
Support (smarttech.com/contactsupport).
To calibrate the interactive flat panel when connected to a computer
1. Open SMART Settings (see Opening SMART Settings on page 29).
2. Press SMART Hardware Settings.
3. If more than one SMART product is connected to your computer, select the
interactive flat panel.
4. Select Advanced Settings from the drop-down list.
5. Press Calibrate, and then follow the on-screen instructions.
The calibration screen appears. This can take a few moments.
6. Press the red target with the tip of a pen. Hold the tip at the center of the target until the target
turns green, and then lift the pen.
The target moves to the next location.
NOTE
You can calibrate a target again by pressing the LEFT ARROW key on your keyboard.
