CHAPTER 3
CONNECTING POWER AND DEVICES
No. Connector
5 HDMI®
SMART Board 6065-V2 and 6075
connector panel
The following diagram and table present the connectors on SMART Board 6065-V2 and 6075
interactive flat panels:
No. Connector
1 USB Micro-A
2 RS-232
3 Stereo 3.5 mm
4 USB Type-B
5 DisplayPort
6 USB Type-B
18 smarttech.com/kb/170642
Connects to
Room computer (video)
Connects to
[N/A]
Room control system
External speakers
Guest laptop (touch)
Guest laptop (video)
Guest laptop (touch)
Notes
The HDMI cable should be HDMI
1.4 compliant and no longer than
16' 5" (5 m).
See page 20 for more
information.
Notes
This connector is a service port.
See page 55.
See page 21.
See page 20 for more
information.
See page 20 for more
information.
See page 20 for more
information.
