APPENDIX A
USING THE ON-SCREEN DISPLAY MENU
Option
500 Hz
1.2 kHz
7.5 kHz
12 kHz
Balance
Audio Input
Sound Reset

OSD menu options

Option
Language
OSD Turn Off
OSD Reset

Setup menu options

Option
Power Save
48 smarttech.com/kb/170642
Values Function
0–100 Sets the sound equalization at
500 Hz
0–100 Sets the sound equalization at
1.2 kHz
0–100 Sets the sound equalization at
7.5 kHz
0–100 Sets the sound equalization at
12 kHz
L50–R50 Balances the left and right volume
OR
-50–50
[Depends on the Sets the audio input source
current video
input]
[N/A] Resets all options in the Sound
menu to their default values
Values Function
[Languages] Sets the on-screen display
menu's language
Off Sets the time of inactivity before
the on-screen display menu
5 seconds
turns off
10 seconds
15 seconds
[N/A] Resets all options in the OSD
menu to their default values
Values Function
On Enables or disables Power Save
mode
Off
Notes
[N/A]
[N/A]
[N/A]
[N/A]
[N/A]
If HDMI is the current video input,
the available values are HDMI and
USB.
If OPS/HDMI is the current video
input, the available values are
OPS Digital and USB.
[N/A]
Notes
[N/A]
[N/A]
[N/A]
Notes
When Power Save mode is enabled
and there is no video input, the
interactive flat panel displays
No Signal for 25 seconds before
turning off.
