Overview
S&C products may be revised to add new features to an
existing assembly. The revision information is listed after
the catalog number with "R" and the revision number.
Parts required for a specific revision are also referred to
with the same Rx designation.
An existing R0 Communication Module can be
upgraded to R3 functionality by installing the R3 Wi-Fi/
GPS transceiver and harnesses.
●
S&C Power Systems Solutions can train utility
personnel to do the R3 retrofit.
●
The retrofit must be done indoors at an electrostatic-
discharge protected workbench.
●
The SCADA radio can be configured in the service
center for a installation at a specific site.
●
The R3 Communication Module can be easily
installed at the site by a line crew.
Note: The IntelliRupter fault interrupter remains fully
operational during the communication module swap.
There will be no service interruption.
Note: When establishing a rotation procedure to swap
communication modules at the site, each SCADA radio
must be configured in the service center for the specific
site at which it will be installed.
NOTICE
These instructions are intended for use only by
personnel trained by S&C Electric Company
Service Personnel
Electrostatic-discharge procedures must be
followed because components are sensitive to
electrostatic-discharge damage .
Use of an SCS 8501 Static Dissipative Mat and
Wrist Groundstrap or a static protected workbench
is required .
NOTICE
The R3 retrofit must be done indoors in a
laboratory or service center environment on a
static-controlled workbench .
NOTICE
Installation of the R3 retrofit kit without proper
training will void the warranty . Contact S&C to
arrange for training provided by S&C Electric
Company Service Personnel .
