Setting the R3 Communication Module to Ethernet IP Configuration
if not already enabled, and make sure the
DHCP Client setpoint is disabled and in the
Off position. Now, configure the Static IP
Address setpoint with the IP address copied
from the IntelliRupter fault interrupter's
Ethernet IP address in Step 6 on page 14.
Do the same for the Netmask setpoint
(which will be the subnet mask copied from the
IntelliRupter fault interrupter) and the Default
Gateway IP Address setpoint (which will be
the default gateway address from the IntelliR-
upter fault interrupter). Then, click on the Save
button in the top right of the screen to save the
configuration. See Figure 35.
Figure 35 . The Ethernet 2 (WAN) section of the Interfaces
screen .
