Setting the R3 Communication Module to Ethernet IP Configuration
When the default username and password are
STEP 1 .
entered, the My User Account screen opens
and prompts assignment of a new password
entry and confirmation. The default password
must be changed to a unique password for
security purposes. The password entry must be
at least eight characters in length and contain
at least one uppercase letter, one lowercase
letter, one number, and one special character.
The Admin or any user with a security
Admin role can modify password complexity.
When entries are complete, click on the
Save button to save the new password. See
Figure 32.
After changing the password, the General
Status screen will be displayed. See
Figure 33.
Click on the Interfaces option in the left menu
STEP 2 .
to open the Interfaces screen. See Figure 34.
Go to the Ethernet 2 (WAN) section and
STEP 3 .
enable the interface by toggling the Enable
Ethernet 2 setpoint to the On position,
18 S&C Instruction Sheet 766-526
Figure 32 . The Change Password screen .
Figure 33 . The General Status screen .
Figure 34 . The Interfaces screen .
.
