11. Warning messages
When the automatic door operator detects a malfunction in the door operation, the program switch screen will show a
numeric code. The code interpretation is summarised in the following table:
Warning
02
SOS
03
Obstruction when
Closing
04
Outside key switch
05
Parameter error
06
Obstruction when
Opening
07
Photocell 1
08
Photocell 2
09
Fire
11
Batteries
12
Interior Radar
13
Exterior Radar
15
Auxiliary processor
16
Side safety device
17
Lock
22
Safety open
23
Safety close
24
Safety close
33
Current leakage
34
Power module
35
Encoder
36
Self-adjustment
fault
49
Critical alarm
Possible cause
Emergency signal enabled.
Obstruction during the closing cycle.
The key has not be removed after 1 min
Door parameter fault.
Obstruction during the opening cycle.
Interior photocell blocked for more than 1
minute.
Exterior photocell blocked for more than 1
minute.
Fire alarm signal triggered.
Battery not overly charged.
Interior radar detection more than 1
minute.
Exterior radar detection more than 1
minute.
Communications failure with auxiliary
processor.
Detection of presence in the passage area
leaves for more than 1 minute
Fault when attempting to close the lock.
Safety open sensor not configured
Safety close sensor not configured
Safety close sensor fault.
Motor insulation fault.
Power module stoppage due to
overcurrent or insulation fault.
Encoder error. One of the two channels of
the encoder is faulty.
Self-adjustment not completed correctly.
Possible general fault in the motor control
microprocessor.
Manusa / Instruction Manual
Corrective action
Check position of folding leaves.
Check emergency stop button.
Check that there are no obstructions
during closure.
Remove the key from the outside key
switch device.
Manusa
Inform the Technical Service.
Check that there are no obstructions in the
opening area.
Clean the photocells. Should the
malfunction persist, inform the
Technical Service.
Clean the photocells. Should the
malfunction persist, inform the
Technical Service.
Check that it is not a false alarm. Should
the malfunction persist, inform the
Technical Service.
If the door has been disconnected for
a while, connect it and wait 24 hours
for the batteries to charge. Should the
malfunction persist, inform the
Technical Service.
Manusa
Inform the Technical Service.
Manusa
Inform the Technical Service.
Should the malfunction persist, inform the
Manusa
Technical Service.
Check that there are no objects within the
detection radius of the sensor.
Manusa
Inform the Technical Service.
Manusa
Inform the Technical Service.
Manusa
Inform the Technical Service.
Manusa
Inform the Technical Service.
Manusa
Inform the Technical Service.
Manusa
Inform the Technical Service.
Manusa
Inform the Technical Service.
Manusa
Inform the Technical Service.
Manusa
Inform the Technical Service.
