3. Chassis: technical features
Manusa
The VISIO + operators offer many assembly varieties depending on the construction requirements:
Operator dimens. (height x depth) [mm]
Optional cover variant 175mm high
Single Operator Length SHORT KIT [mm]
(Standard size sliding clearance) [mm]
Single Operator Length LONG KIT [mm]
(Standard size sliding clearance) [mm]
Bi-parting Oper. Length SHORT KIT [mm]
(Standard size sliding clearance) [mm]
Bi-parting Oper. Length LONG KIT [mm]
(Standard size sliding clearance) [mm]
Maximum height clearance [mm]
Admissible mounting
Admissible suspension beam [mm]
Operator dimensions with susp. beam
Height x Depth [mm]
* The indicate dimensions correspond to the length of the standard operator kits, which in the case of the LONG KIT are the maximum possible
operator dimensions. Operators are available in KIT format at pre-determined size, or custom-made upon request.
** Clear Widths indicated correspond to the minimum and maximum possible width of passage for the indicated length and type of operator. The
maximum width of the passage will always be conditioned to the type and the weight of the moving leaf. The minimum indicated is considering that
the operator includes a lock.
*** The maximum clear height will always be conditioned to the type of leaf used and the maximum weight of the moving leaf.
In a freestanding assembly, it is recommended to use a system of suspension beams in order to reinforce the operator
structure. If the extructure is not strong enough is mandatory to use goal post
100 mm height x 253 mm depth
125 mm height x 262 mm depth
Chassis features
Visio+ 100
100 x 203
--
2910*
(750-1430)**
4210*
(750-2055)**
4210*
(980-2055)**
5810*
(980-2855)**
3000***
Front
Side
100X50
100 x 253
Self-supporting suspension beams
125 mm height x 212 mm depth
125 mm height x 280 mm depth
Manusa / Instruction Manual
Visio+ 125
Visio+ 125 Telescopic
Visio+ 125HD
125 x 180
175x180
2910*
(750-1430)**
4210*
(750-2055)**
4210*
(900-2055)**
5810*
(900-2855)**
3000***
Front
Side
Top
125X30
125X50
125 x 212
125 x 230
125 mm heigh x 230 mm depth
D01380EN-v5
125 x 230
175 x 230
2910*
(1050-1903)**
4210*
(1050-2500)**
4210*
(1800-2740)**
5810*
(1800-3806)**
3000***
Front
Side
Top
125X30
125X50
125 x 262
125 x 280
