8. Machine identification
Manusa
automatic doors have been especially designed to allow people fast, safe and controlled access to facilities of
all types.
VISIO+
The operator has been designed with design in mind:
• Less visual impact thanks to its small size.
• Better integration with architectural assemblies.
• Possibility of including the Smart program switch, with a very intuitive digital control panel (3" LCD screen).
This manual contains the basic instructions for the practical use of your automatic door. Read it carefully and consult an
authorised fitter should you have any queries.
For your own safety, follow the technical instructions given in this manual at all times.
and failure resulting from non-compliance with these instructions.
Lastly, we would like to thank you for choosing a product from the Manual range, a company with over 50 years of expe-
rience in the design, manufacturing and installation of automatic access systems.
Outdoor detector
Indoor detector
External push button
Inner push button
Outside key switch
Sliding leaf
Fixed leaf
9. Operation and use
Manusa
automatic doors operate automatically. Manual operation is only foreseen for cleaning, maintenance and
adjustment.
All checks and adjustments necessary for commissioning Manusa automatic doors may only be carried out by author-
ised technical staff.
9.1 Standard stopping and emergency stopping
Standard stopping of Manusa automatic doors as well as their start-up is performed automatically. Emergency situations
are automatically managed by the machine itself. However, an optional emergency stop may be installed.
Clear width
Manusa / Instruction Manual
D01380EN-v5
Manusa
is not liable for damage
Operator
Program switch
Fixed leaf
Photocells
Sliding leaf
16
