4. Leaves
The VISIO operator is compatible with the entire range of
thickness of up to 50mm without the need for intermediate adaptors.
Three different types of leaf assembly are allowed in relation to the operator:
Under the Lintel (BD)
Fixed leaf mounted under the door lintel
The following table shows all available leaves and their compatibility with the different chassis types and fixed-leaf
assembly systems:
Leaf compatibility
Transparent A20-1
Transparent A20-1R
Transparent A35-1
Bare A20-2
Bare A20-2R
Bare A35-2
Framed A20-4
Framed A30-4
Framed A35-RPT
Framed A44-4
Framed A45-4
Commercial Framed
Panic break-out A40-S2
Panic break-out A44-S4
Panic break-out A45-S2
Panic break-out A45-S4
Panelled P50
Manusa
leaves, as well as any other commercial leaves with a
Type of leaf assembly
Below the Operator (BO)
Fixed leaf mounted below the operator
Visio+ 100
BO
BO
BO
BO
BO
BO
BO
-
-
-
-
-
-
-
-
-
-
Manusa / Instruction Manual
Hidden Rail (PO)
Hidden leaf with 175mm operator
Visio+ 125 Visio+ 125 Telesc.
Visio+ 125HD
BO ; BD
BO ; BD
BO ; BD
BO ; BD
BO ; BD
BO ; BD
BO ; BD
BD
BD
BD
BD
BD
BD
BD
BD
BD
BD
D01380EN-v5
-
-
-
BO
BO
BO
BO
BD
BD
-
-
-
-
-
-
-
-
