9.2 Operating and remote control switch modes
Manusa
The operating modes for
Door open (Ab)
Door closed (CE)
9.3 (Mode) remote control switch
The remote control switch enables you to change operating mode and view the status of the automatic door.
Smart program switch
1.
LCD screen indicating the operating mode selected in a language to be
chosen from the following: Spanish, Catalan, French and English.
It is also possible to view the time or the number of cycles completed.
Where the monitoring system detects an abnormality, a message and a
numeric value indicating the type of abnormality are displayed.
2/4.
Selection buttons.
3.
Confirmation button
Óptima program switch
1.
7-Segment, 2-digit display indicating the operating mode selected in a
language to be chosen from the following: Spanish, French, English,
German, Italian, Portuguese, Dutch, Catalan. Where the monitoring system
detects an abnormality, a flashing numeric value indicating the type of
abnormality is displayed.
2/3.
Buttons reserved for the technical service.
4.
Buttons to select the operating mode.
5.
Infra-red receiver, fitted as standard, for the remote control of the door
using a remote-control unit (optional).
Óptima+ program switch
1. User mode:
varies. Its function can only be changed by the adminis-
trator. Its default function is "Exit Only".
2. Closed mode:
mode closes the door and releases the leaves. In doors
with a lock, the leaves will close and be locked by it.
3. Automatic mode:
sensor is triggered, either interior or exterior.
4. Open mode:
leaves can be moved by hand.
doors are as follows:
Reduction opening (A1-A4)
Automatic (AU)
The key is configurable, so its function
In doors without a lock, this operating
The door will open whenever a
the door will open, after which the
Manusa / Instruction Manual
D01380EN-v5
Exit only (SS)
