CEI-4x10GBASE-T Network Adapter
5.3. 10GbE Adaptor Card Installation
Below is an example (illustration purposes only) of a CEI-4x10GBASE-T adapter card installed on an Express-BASE7 carrier board with a Type 7 Express-
ID7 module.
Note: If input 5VSB-to-10GbE adapter card is needed for testing purposes, a specific cable and connection are required. Please contact an ADLINK
representative for details.
Page 19
Copyright © 2023 ADLINK Technology, Inc.
PICMG COM.0 R3.1
