CEI-4x10GBASE-T Network Adapter
Page 15
Row B
Pin Name
B16 NC
B17 CEI_INT#
B18 GND
B19 NC
B20 NC
B21 GND
B22 GND
B23 10G_KR_RX3+
B24 10G_KR_RX3-
B25 GND
B26 GND
B27 10G_KR_RX2+
B28 10G_KR_RX2-
B29 GND
B30 10G_PHY_RST_01 (TBC)
B31 CEI_RST#
B32 GND
B33 10G_KR_RX1+
B34 10G_KR_RX1-
B35 GND
B36 GND
B37 NC
B38 NC
B39 GND
B40 GND
B41 10G_KR_RX0+
B42 10G_KR_RX0-
B43 GND
B44 GND
B45 10G_SDP3
B46 10G_SDP2
B47 GND
B48 10G_SDP1
B49 GND
Copyright © 2023 ADLINK Technology, Inc.
Row A
Pin Name
A16 NC
A17 NC
A18 GND
A19 NC
A20 GND
A21 NC
A22 NC
A23 GND
A24 GND
A25 10G_KR_TX3+
A26 10G_KR_TX3-
A27 GND
A28 GND
A29 10G_KR_TX2+
A30 10G_KR_TX2-
A31 GND
A32 CEI_SDA (TBC)
A33 CEI_SCL (TBC)
A34 GND
A35 10G_KR_TX1+
A36 10G_KR_TX1-
A37 GND
A38 GND
A39 CEI_MDIO
A40 CEI_MDC
A41 GND
A42 GND
A43 10G_KR_TX0+
A44 10G_KR_TX0-
A45 GND
A46 GND
A47 NC
A48 CEI_PRSNT#
A49 GND
PICMG COM.0 R3.1
