CEI-4x10GBASE-T Network Adapter
Page 16
Row B
Pin Name
B50 NC
B51 NC
B52 GND
B53 GND
B54 NC
B55 NC
B56 GND
B57 GND
B58 NC
B59 NC
B60 GND
B61 GND
B62 NC
B63 NC
B64 GND
B65 GND
B66 NC
B67 NC
B68 GND
B69 GND
B70 NC
B71 NC
B72 GND
B73 GND
B74 NC
B75 NC
B76 GND
B77 GND
B78 NC
B79 NC
B80 GND
B81 NC
B82 NC
