User Guide
RIBBON CABLE CONNECTION BETWEEN THE ADIS16501 AND EVAL-ADIS-FX3
Table 2. Standard Electronic Components and Usage (Continued)
Component Description
Microcontroller (or Processing Unit)
FX3 Reset Button.
ADIS16501 IMU Chip
FX3 Bootloader Recover
analog.com
Function
It acts as the brain of the ADIS16501-2/PCBZ,
processing all data from the IMU and managing
communications with other connected devices.
It provides a manual method to reset the ADIS16501-2/
PCBZ to its default operational state without needing to
power cycle
The core sensor unit offers precise angular rates and
acceleration measurements.
If the ADIS16501-2/PCBZ is not detected, reset the
EVAL-ADIS-FX3 by unplugging the USB cable or
pressing the RESET button. If this reset is unsuccessful,
press and hold the RECOVERY button while plugging
the EVAL-ADIS-FX3 into the PC to force recovery
mode.
EVAL-ADIS16501
Usage Recommendations
It is programmed to customize its operation for specific
applications under recommended conditions.
Use the reset button to troubleshoot issues or
to reset the ADIS16501-2/PCBZ configuration during
development and testing.
Optimal placement on the board to minimize noise and
vibration.
If required, use the bootloader recovery for device
detection issues and firmware recovery during
development and testing.
