CHARACTERISTICS:

The HD67599-A1 is a EtherNet/IP / J1939 Converter.
It allows the following characteristics:
Up to 496 bytes in reading and 496 bytes in writing;
Triple isolation between J1939 - Power Supply, J1939 - Ethernet, Ethernet - Power Supply;
Two-directional information between J1939 bus and EtherNet/IP bus;
Mountable on 35mm Rail DIN;
Wide power supply input range: 8...24V AC or 12...35V DC;
Wide temperature range: -40°C / 85°C [-40°F / +185°F].

CONFIGURATION:

You need Compositor SW67599 software on your PC in order to perform the following:
Define the parameter of EtherNet/IP line;
Define the parameter of J1939 line;
Determinate which EtherNet/IP byte transfer in J1939 and viceversa;
Update the device.
