SET COMMUNICATION:

This section define the fundamental communication parameters of two buses, EtherNet/IP and J1939.
By Pressing the "Set Communication" button from the main window for SW67599 (Fig. 2) the
window "Set Communication" appears (Fig. 3).
The means of the fields for "EtherNet/IP" are:
In the fields "IP ADDRESS" insert the IP address that you want to give to the Converter;
In the fields "SUBNET
In the fields "GATEWAY" insert the default gateway that you want to use. This feature can be
enabled of disabled pressing the Check Box field;
In the field "Port" the port used for EtherNet/IP communication is defined. The port has a fixed
value of 44818;
In the field "Number Byte
is defined (at maximum it is possible to use 500 byte);
In the field "Number Byte
is defined (at maximum it is possible to use 500 byte).
The means of the fields for the "J1939" section are:
In the field "Baudrate" the velocity of the J1939 bus is defined;
In the field "TimeOut Data
reliable, in the EtherNet/IP data array you read "0". It is possible to use this function only for
the "Receive Frames";
If the field "Enable Peer to
PGN inserted in the "Receive Frames" section;
In the field "Device ID" the ID of J1939 side of the converter is defined.
ADFweb.com S.r.l.
Mask" insert the SubNet Mask;
Input" the number of byte from the EtherNet/IP to the Converter
Output" the number of byte from the Converter to the EtherNet/IP
(s)" insert a time; when this time is elapsed and the data isn't
Peer" is checked, the Converter accepts all the ID that have the
User Manual EtherNet/IP / J1939 - Converter
Document code: MN67599_ENG Revision 1.100
Figure 3: "Set Communication" window
Page 16 of 28
