ADF Web HD67599-A1 User Manual

Ethernet/ip / j1939 - converter
Hide thumbs

Advertisement

Quick Links

Download this manual
Industrial Electronic Devices
User Manual
Revision 1.100
English
EtherNet/IP / J1939 - Converter
(Order Code: HD67599-A1)
For Website information:
www.adfweb.com?Product=HD67599
For Price information:
www.adfweb.com?Price=HD67599-A1
Benefits and Main Features:
Two EtherNet/IP ports
Temperature range: -40°C/+85°C (-40°F/+185°F)
User Manual
ADFweb.com S.r.l.
User Manual EtherNet/IP / J1939 - Converter
Document code: MN67599_ENG
For others Ethernet/IP products see also the following link:
Converter EtherNet/IP to
www.adfweb.com?Product=HD67077
www.adfweb.com?Product=HD67091
www.adfweb.com?Product=HD67159
www.adfweb.com?Product=HD67174
www.adfweb.com?Product=HD67588
www.adfweb.com?Product=HD67589
www.adfweb.com?Product=HD67590
www.adfweb.com?Product=HD67591
www.adfweb.com?Product=HD67592
www.adfweb.com?Product=HD67593
www.adfweb.com?Product=HD67594
www.adfweb.com?Product=HD67595
www.adfweb.com?Product=HD67596
www.adfweb.com?Product=HD67597
www.adfweb.com?Product=HD67598
www.adfweb.com?Product=HD67627
www.adfweb.com?Product=HD67660
www.adfweb.com?Product=HD67663
www.adfweb.com?Product=HD67664
www.adfweb.com?Product=HD67682
www.adfweb.com?Product=HD67722
www.adfweb.com?Product=HD67744
www.adfweb.com?Product=HD67771
www.adfweb.com?Product=HD67807
www.adfweb.com?Product=HD67840
www.adfweb.com?Product=HD67871
www.adfweb.com?Product=HD67906
www.adfweb.com?Product=HD67945
www.adfweb.com?Product=HD67974
www.adfweb.com?Product=HD67B16
www.adfweb.com?Product=HD67B39
www.adfweb.com?Product=HD67B78
www.adfweb.com?Product=HD67C63
www.adfweb.com?Product=HD67D25
www.adfweb.com?Product=HD67E27
www.adfweb.com?Product=HD67E77
www.adfweb.com?Product=HD67F25
Revision 1.100
Page 1 of 28
(M-Bus)
(M-Bus Wireless)
(SNMP Agent)
(SNMP Manager)
(DMX)
(NMEA2000)
(Serial)
(Modbus Master)
(Modbus Slave)
(PROFIBUS Master)
(PROFIBUS Slave)
(CAN)
(CANopen)
(DeviceNet Master)
(DeviceNet Slave)
(S7comm)
(PROFINET Slave)
(Modbus TCP Slave)
(Modbus TCP Master)
(BACnet Slave)
(BACnet Master)
(IEC 61850 Server)
(IEC 61850 Client)
(KNX)
(DALI)
(IO-Link Master)
(HART)
(MQTT)
(IO-Link Slave)
(OPC UA Client)
(OPC UA Server)
(PROFINET Master)
(EnOcean)
(LoRaWAN)
(EtherCAT Slave)
(EtherCAT Master)
(LoRaWAN Gateway)

Advertisement

loading
Need help?

Need help?

Do you have a question about the HD67599-A1 and is the answer not in the manual?

Questions and answers

Related Manuals for ADF Web HD67599-A1

Summary of Contents for ADF Web HD67599-A1

  • Page 1 Revision 1.100 English For others Ethernet/IP products see also the following link: Converter EtherNet/IP to EtherNet/IP / J1939 - Converter www.adfweb.com?Product=HD67077 (M-Bus) www.adfweb.com?Product=HD67091 (M-Bus Wireless) (Order Code: HD67599-A1) www.adfweb.com?Product=HD67159 (SNMP Agent) www.adfweb.com?Product=HD67174 (SNMP Manager) www.adfweb.com?Product=HD67588 (DMX) For Website information: www.adfweb.com?Product=HD67589 (NMEA2000) www.adfweb.com?Product=HD67599...

  • Page 2: Table Of Contents

    User Manual EtherNet/IP / J1939 - Converter Document code: MN67599_ENG Revision 1.100 Page 2 of 28 Industrial Electronic Devices INDEX: UPDATED DOCUMENTATION: Dear customer, we thank you for your attention and we remind you that you need to check that the following document is: Page INDEX Updated...

  • Page 3: Security Alert

    User Manual EtherNet/IP / J1939 - Converter Document code: MN67599_ENG Revision 1.100 Page 3 of 28 Industrial Electronic Devices SECURITY ALERT: ENERAL NFORMATION To ensure safe operation, the device must be operated according to the instructions in the manual. When using the device, legal and safety regulation are required for each individual application.

  • Page 4: Examples Of Connection

    User Manual EtherNet/IP / J1939 - Converter Document code: MN67599_ENG Revision 1.100 Page 4 of 28 Industrial Electronic Devices EXAMPLES OF CONNECTION: ADFweb.com S.r.l.

  • Page 5: Connection Scheme

    User Manual EtherNet/IP / J1939 - Converter Document code: MN67599_ENG Revision 1.100 Page 5 of 28 Industrial Electronic Devices CONNECTION SCHEME: Figure 1: Connection scheme for HD67599-A1 ADFweb.com S.r.l.

  • Page 6: Characteristics

    Page 6 of 28 Industrial Electronic Devices CHARACTERISTICS: The HD67599-A1 is a EtherNet/IP / J1939 Converter. It allows the following characteristics: Up to 496 bytes in reading and 496 bytes in writing; Triple isolation between J1939 - Power Supply, J1939 - Ethernet, Ethernet - Power Supply;...

  • Page 7: Power Supply

    The devices can be powered at 8…24V AC and 12…35V DC. For more details see the two tables below. Vmin Vmax Vmin Vmax Consumption at 24V DC: Device Consumption [W/VA] HD67599-A1 Caution: Not reverse the polarity power HD67599-A1 ADFweb.com S.r.l.

  • Page 8: Function Modes

    User Manual EtherNet/IP / J1939 - Converter Document code: MN67599_ENG Revision 1.100 Page 8 of 28 Industrial Electronic Devices FUNCTION MODES: The device has got two functions mode depending of the position of the Dip1 of ‘Dip-Switch A’: The first, with Dip1 in Off position (factory setting), is used for the normal working of the device. The second, with Dip1 in On position, is used for upload the Project/Firmware.

  • Page 9: Leds

    User Manual EtherNet/IP / J1939 - Converter Document code: MN67599_ENG Revision 1.100 Page 9 of 28 Industrial Electronic Devices LEDS: The device has got six LEDs that are used to give information of the functioning status. The various meanings of the LEDs are described in the table below. Normal Mode Boot Mode 1: ON (green)

  • Page 10: Ethernet/Ip

    The EtherNet/IP connection must be made using Connector3 and/or Connector4 of HD67599-A1 with at least a Category 5E cable. The maximum length of the cable should not exceed 100m. The cable has to conform to the T568 norms relative to connections in cat.5 up to 100 Mbps.

  • Page 11: J1939

    User Manual EtherNet/IP / J1939 - Converter Document code: MN67599_ENG Revision 1.100 Page 11 of 28 Industrial Electronic Devices J1939: To terminate the J1939 line with a 120Ω resistor it is necessary that the Dip1 of ‘Dip-Switch B’ is at ON position (like in figure). Cable characteristics: DC parameter: Impedance...

  • Page 12: Use Of Compositor Sw67599

    User Manual EtherNet/IP / J1939 - Converter Document code: MN67599_ENG Revision 1.100 Page 12 of 28 Industrial Electronic Devices USE OF COMPOSITOR SW67599: To configure the Converter, use the available software that runs with Windows called SW67599. It is downloadable on the site www.adfweb.com and its operation is described in this document.

  • Page 13: New Configuration / Open Configuration

    User Manual EtherNet/IP / J1939 - Converter Document code: MN67599_ENG Revision 1.100 Page 13 of 28 Industrial Electronic Devices NEW CONFIGURATION / OPEN CONFIGURATION: “New Configuration” button creates the folder which contains the entire device’s configuration. A device’s configuration can also be imported or exported: To clone the configurations of a Programmable “EtherNet/IP / J1939 - Converter”...

  • Page 14: Software Options

    User Manual EtherNet/IP / J1939 - Converter Document code: MN67599_ENG Revision 1.100 Page 14 of 28 Industrial Electronic Devices SOFTWARE OPTIONS: By pressing the “Settings” ( ) button there is the possibility to change the language of the software and check the updatings for the compositor.
  • Page 15 User Manual EtherNet/IP / J1939 - Converter Document code: MN67599_ENG Revision 1.100 Page 15 of 28 Industrial Electronic Devices In the section “Software Settings”, it is possible to enable/disable some keyboard’s commands for an easier navigation inside the tables contained in the different sections of the software.

  • Page 16: Set Communication

    User Manual EtherNet/IP / J1939 - Converter Document code: MN67599_ENG Revision 1.100 Page 16 of 28 Industrial Electronic Devices SET COMMUNICATION: This section define the fundamental communication parameters of two buses, EtherNet/IP and J1939. By Pressing the “Set Communication” button from the main window for SW67599 (Fig. 2) the window “Set Communication”...

  • Page 17: Receive Frames

    User Manual EtherNet/IP / J1939 - Converter Document code: MN67599_ENG Revision 1.100 Page 17 of 28 Industrial Electronic Devices RECEIVE FRAMES: By pressing the “Receive Frames” button from the main window for SW67599 (Fig. 2) the “Receive Frames” window appears (Fig. 4). The data of the columns have the following meanings: In the field “Data...

  • Page 18: Send Frames

    User Manual EtherNet/IP / J1939 - Converter Document code: MN67599_ENG Revision 1.100 Page 18 of 28 Industrial Electronic Devices SEND FRAMES: By pressing the “Send Frames” button from the main window for SW67599 (Fig. 2) the “Send frames” window appears (Fig. 5). The data of the columns have the following meanings: In the field “Priority”...

  • Page 19: Update Device

    User Manual EtherNet/IP / J1939 - Converter Document code: MN67599_ENG Revision 1.100 Page 19 of 28 Industrial Electronic Devices UPDATE DEVICE: By pressing the “Update Device” button, it is possible to load the created Configuration into the device; and also the Firmware, if necessary. This by using the Ethernet port. If you don’t know the actual IP address of the device you have to use this procedure: Turn OFF the Device;...
  • Page 20 User Manual EtherNet/IP / J1939 - Converter Document code: MN67599_ENG Revision 1.100 Page 20 of 28 Industrial Electronic Devices Note: When you receive the device, for the first time, you also have to update the Firmware in the HD67599 device. Warning: If Fig.

  • Page 21: Mechanical Dimensions

    User Manual EtherNet/IP / J1939 - Converter Document code: MN67599_ENG Revision 1.100 Page 21 of 28 Industrial Electronic Devices MECHANICAL DIMENSIONS: Figure 8: Mechanical dimensions scheme for HD67599-A1 ADFweb.com S.r.l.

  • Page 22: Ordering Informations

    Enclosure Type A: 1M, 35mm DIN Rail mounting Device Family HD67599: EtherNet/IP / J1939 - Converter Order Code: HD67599-A1 EtherNet/IP / J1939 - Converter ACCESSORIES: Order Code: AC34011 35mm Rail DIN - Power Supply 220/240V AC 50/60Hz – 12 V DC Order Code: AC34012 35mm Rail DIN - Power Supply 220/240V AC 50/60Hz –...

  • Page 23: Plc Configuration

    User Manual EtherNet/IP / J1939 - Converter Document code: MN67599_ENG Revision 1.100 Page 23 of 28 Industrial Electronic Devices PLC CONFIGURATION: The configuration and commissioning of the EtherNet/IP Converter as described on the following pages was accomplished with the help of the “RSLogix 5000”...
  • Page 24 “HD67599” and the IP-address assigned is 192.168.0.5. For the Comm Format “Data – SINT” shall be selected as the data type. The HD67599-A1 can uses up to 500 bytes for input assembly instance 101 and 500 bytes for output assembly instance 100.
  • Page 25 User Manual EtherNet/IP / J1939 - Converter Document code: MN67599_ENG Revision 1.100 Page 25 of 28 Industrial Electronic Devices 4) After the configuration is completed, the controller tags are created. ADFweb.com S.r.l.
  • Page 26 User Manual EtherNet/IP / J1939 - Converter Document code: MN67599_ENG Revision 1.100 Page 26 of 28 Industrial Electronic Devices 5) With “RSLinks Classic Lite”, after have done a network scan (RSWho), and finding the EtherNet/IP device, it is possible to load the EDS file for the device in order to have the “Module Info”...

  • Page 27: Disclaimer

    User Manual EtherNet/IP / J1939 - Converter Document code: MN67599_ENG Revision 1.100 Page 27 of 28 Industrial Electronic Devices DISCLAIMER: All technical content within this document can be modified without notice. The content of the document is a under continual renewal. For losses due to fire, earthquake, third party access or other accidents, or intentional or accidental abuse, misuse, or use under abnormal conditions repairs are charged to the user.

  • Page 28: Warranties And Technical Support

    User Manual EtherNet/IP / J1939 - Converter Document code: MN67599_ENG Revision 1.100 Page 28 of 28 Industrial Electronic Devices WARRANTIES AND TECHNICAL SUPPORT: For fast and easy technical support for your ADFweb.com SRL products, consult our internet support at www.adfweb.com. Otherwise contact us at the address support@adfweb.com RETURN POLICY: If while using your product you have any problem and you wish to exchange or repair it, please do the following:...
