Battery Replacement; Spare Parts And Technical Support - Infrico Lab Care Plus ULF70086 Service Manual

2) Disconnect the equipment
3) Open the outer door and inner doors
4) Leave the freezer standing with the doors open for at least 24 hours. This allows both the internal
cooling system and the foam system to be heated to room temperature.
5) Discard the ice and clean the water that is on the bottom of the cabinet.
6) If there is an ice smell, wash the interior with a solution of baking soda and warm water.
7) Clean the exterior with any common cleaner (See section 5.13)
8) Close de doors, restart the freezer and reload s indicated in section 2.3 Initial load.
12.2

Battery replacement

OBLIGATION!: Make sure the device is disconnected from the mains before carrying out any
maintenance or repair work.
The equipment consists of a 12V-12Ah Lead-Acid rechargeable battery. Battery should be replaced only
with another one of the same characteristics as mentioned above.
You should order Technical Service to replace the battery every 12 months.
PROHIBITION!: The battery may only be replaced by an authorised technical support service provider.
12.3

Spare Parts and Technical Support

OBLIGATION!: Make sure the device is disconnected from the mains before carrying out any
maintenance or repair work.
If there is no recommended technical support service provider in your area, please contact us for a list
of technical support service providers.
If the problem persists after the appropriate verifications, DO NOT MAKE ANY REPAIRS YOURSELF.
Contact our Technical Support Service, and have the model and serial number of the device at hand (located on
the technical data label),
WARNING!: If spare parts are needed, always insist on factory authorized spare parts.
Note: Wiring diagrams, exploded view diagrams, descriptions, calibration instructions and other
information regarding the equipment are available upon request to assist the authorized technical support
service provider in a repair.
Service Manual and Warranty
46
