S06 3
S07 0
S08 5
PARAM. DEFECT MIN.
C01 2
C02 1
C03 120
C04 1
C05 1
C07 0
C08 1
0 = STOPPED OF the COMPRESSOR - during defrost, the
compressor will remain dull and the exit of defrost will remain
deactivated.
1 = ELECTRICAL - during defrost, the compressor will remain
dull and the exit of defrost will activate throughout the cycle
of 2
defrost = BY HOT GAS - during defrost, the exit of defrost will
activate and later S07 the compressor will also activate.
during defrost, the ventilator of the evaporator will be
activated depending on the F05 parameter, whereas the
ventilator of the condenser is activated depending on the F06
parameter.
0 300 min Dripping time.
0 300 s Compressor start-up delay for HotGas
1 48 h Compressor operating time for automatic defrost start-up
MAX. M.U.
function of the switch of door
0 = entered this deactivated
1 = compressing and ventilators of the evaporator estan dull
0 2 ---
when the door is open
2 = ventilators of the evaporator are dull when the door is
open
interrupting polarity of door
0 1 --- 0 = closed door = contact is open
1 = closed door = contact is closed
0 600 s Retardation door alarm
Enables buzzer
0 1 --- 0 = Disabled
1 = Enabled
Light Relay Setup
0 1 --- 0 = Turns on using the keyboard and micro door light
1 = Turns on using the keyboard
Enables evaporator probe
0 1 --- 0 = Disabled
1 = Enabled
Enables condenser probe
0 1 ---
0 = Disabled
Service Manual and Warranty
ALARMS
