6

DIGITAL PLUS CONTROLLER

6.1

Preliminary Signs

By 'operation mode' we mean the following modes:
o
'ON' mode (the device is turned on and the regulators can be turned on)
o
'Stand-by' mode (the device is turned on and the regulators are turned off)
o
'OFF' mode (the device is not turned on)
'Turn on' means switching from 'stand-by' to 'ON' mode. 'Turn off' means switching from 'ON' mode to
'stand-by' mode.
Each time the device is connected to the power supply, it will return to the mode it was in at the time of
disconnection.
6.2

Commissioning the Device

Operate as follows:
1.- Connect the device to the power source: A 'loading' message
will be displayed on screen for 10 seconds.
2.- The device will be on 'stand-by' mode, and the date and
time will be displayed on the screen. In the event that the controller is
stored for longer than the backup battery capacity, the date and time
will require resetting.
3.- Press the ON / STAND-BY key which
The home screen will be displayed as shown in the image.
4.- Follow the device setting procedure explained in chapter 7.
5.- Connect the loads to the power source.
6.3

Turning the device ON/OFF

To activate the ON/OFF device, operate as follows:
1.- Make sure that the keyboard is not locked and that there are no processes in progress.
2.- Press the ON/STAND-BY key.
Service Manual and Warranty
is illuminated:
12
