6.11

Battery test

To test the battery, it is required to carry out a control system's power failure drill. The 'battery test'
consists in cutting the power source feeding the battery charger, but not the one feeding the control module.
This way, control of the system can be regained after 10 seconds by activating the relay.
The audible alarm will be enabled throughout the test, which can be considered successful when the
'TEST OK' legend is displayed on the screen, meaning that the lack of electrical power has been detected by the
digital input and that the battery is full, while a low battery level would have shut it off.
When resetting the session, the "FAILED" message will be displayed to inform that the battery is not working
properly.
The operations will return to normal after pressing the "OK" key.
7

SETTINGS

7.1

Preliminary notes

To access the menu functions on the display, follow the steps below:
The following is a list of the main selection keys:
- HOME key: Displays the main screen
- ESCAPE key
- and key: Make it possible to navigate the menus
- + and - : Make it possible to set the desired value
- SET key: Make it possible to confirm the desired value
: Makes it possible to return to the previous screen
