Infrico Infricool Series User Manual And Warranty

Blast chillers and shock freezers
Hide thumbs

Advertisement

Quick Links

Download this manual
Blast chillers and shock freezers
Infricool series
User manual and warranty

Advertisement

loading
Need help?

Need help?

Do you have a question about the Infricool Series and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for Infrico Infricool Series

Summary of Contents for Infrico Infricool Series

  • Page 1 Blast chillers and shock freezers Infricool series User manual and warranty...
  • Page 2 SERVICE AND INSTALLATION MANUAL FOR INFRICOOL BLAST CHILLERS AND SHOCK FREEZERS CONTENTS GENERAL INFORMATION ........................ 2 SAFETY PRECAUTIONS ........................2 SERIAL DATA PLATE ........................3 RECEIVING AND INSPECTING THE EQUIPMENT ............... 3 INSTALLATION ..........................4 5.1. Location ............................. 4 5.2. Uncrating ............................
  • Page 3 This product has been manufactured under strict quality controls and meets all the requirements established by Infrico. Before leaving the factory, each unit has been tested, guaranteeing its quality. This equipment has been manufactured with recyclable materials, through a productive process that respects the environment.
  • Page 4 4. RECEIVING AND INSPECTING THE EQUIPMENT • All Infrico products are factory tested for performance and are free from defects when shipped. • When you recive your device, it should be carefully examined in order to detect any possible damage caused during delivery.
  • Page 5 5.2. Uncrating These Infrico units are shipped from the factory on a wooden pallet and packaged in a wooden container. The wooden is attached to the wooden base with the use of large screws. These should be first removed to avoid scratching the unit when lifting off the crate.
  • Page 6 NOTE: Infrico does not recommend laying the unit down on its front, side or back. However, you must be certain to allow the unit to remain in an upright position afterwards for at least 24 hours before plugging it in so that the compressor oil and refrigerant may settle.
  • Page 7 These models are supplied with adjustable legs. These must be adjusted until the unit keeps completely stable and levelled. NOTE: If the unit has to be placed on its back, make sure it stands upright for 24 hours before being powered up to assure oil return to compressor. Casters in lieu of legs are supplied as an optional accessory for all our models.
  • Page 8 It prevents us from the electrical risk of the device. NOTE: Infrico requires that a sole use circuit be dedicated for the unit. Failure to do so voids warranty. NOTE: The unit is designed to operate with a voltage fluctuation of 5% of the voltage indicated on the cabinet serial data plate.
  • Page 9 WARNING!: Any alterations to this cord and plug could cause an electrical hazard and will void the factory warranty. Furthermore, never use an adapter plug. WARNING!: Infrico will not warranty any units that are connected to an extension cord. 7. STARTUP PROCEDURE After the cabinet has been installed, levelled, cleaned and electrically connected in accordance with this manual, it is ready to operate.
  • Page 10 A shock chiller cycle, on the other hand, tends to reduce the ice microcrystals formation inside the freezed product. This microcrystal, when formed, affect the organoleptic properties of the food. Standard values for these cycles are the following: Blast Chillers Shock Freezing Initial product temperature 70°C (158˚F)
  • Page 11 At the end of the cycle a preservation phase is set, where the blast-chiller will reach and keep the preservation target temperature inside the chamber. The end of the cycle is indicated with an audible whistle. This units are equipped with a digital temperature controller located in the upper frontal panel. The controller is equipped with a very powerfull display, with 3 digits, decimal dots and signs.
  • Page 12 If pressed for more than 3 sec., unit is If pressed for more than 2 sec., cycle is actived/deactived. permanently finished, and preservation starts. *if it is a CHILL-type cycle: setpoint=2ºC (36 ˚F *if it is a FREEZE-type cycle: setpoint=-20ºC ˚F If pressed for more than 1 sec., auxiliary If pressed for more than 1 sec., auxiliary output 2...
  • Page 13 Step 2. Blast-chilling cycle selection: press selection buttons. Pressing NEW button sends to step 1. Each individual selection is visualized on the display with its corresponding “o”. See table below. AUTOMATIC PHASE 1 PHASE 2 defrost conservation before ambient ambient product time ambient...
  • Page 14 Startup-clock: ON if RTC At least one timed CLOCK Clock alarm is activated defrost is configured. Demister heating LIGHT auxiliary output is LIGHT auxiliary output is LIGHT activated deactivated function activated malfunction (example: ASSISTANCE No malfunction EEPROM error or broken down probes) Enabled fucntion (HA HACCP alarm HACCP...
  • Page 15 These models defrost stopping the compressor, and the evaporator fan works during the defrost cycle. How to make a manual defrost If a manual defrost cycle is necessary, if right temperature conditions exist, press the button for 5 seconds. 8.7. Loading product •...
  • Page 16 • Disconnect the unit from the power supply and remove all food products from inside. • Open all doors and allow the cabinet to reach room temperature. Remove all accessories and clean them with a baking soda or mild soap and warm water solution. Dry all the accessories completely with a soft, clean cloth.
  • Page 17 system operation. Dirty condensers result in compressor failure and product loss. If the condenser coil is dirty or blocked, follow this instruction: • Disconnect the power supply. • Remove the lower grill on the rear of the cabinet. • Once that condenser’s surface is free, it should be cleaned using a soft brush or a vacuum.
  • Page 18 Infrico Technical Assistance Service (SAT) Tel: 00 34 957 51 14 68 Fax: 00 34 957 59 51 06 Email: sat@infrico.com www.infrico.com NOTE: If you need a spare part, always insist on factory authorized spare parts. TROUBLE SHOOTING CHART Many operating problems are derived from causes that can be easily eliminated without the need to contact the Technical Department.
  • Page 19 touching. 2. Separate the tubes in contact. 3. Loose screws in a particular part. 3,6. Tighten the loose screws. 4. Condenser or evaporator fan causes 4. Level the equipment and tighten any vibrations. loose screw. 5. Too low oil charge in compressor. 5.
  • Page 20 11.1. Two years parts & labor warranty Infrico USA, Corp. (“Infrico”) warrants to the original customer that the Infrico brand equipment sold hereunder, except for parts and accessories which carry the warranty of a supplier (the “Equipment”) will be free from defects in material and factory workmanship under normal conditions of...
  • Page 21 If there is a defect in material or factory workmanship covered by this Warranty reported to Infrico during the period the applicable Warranty is in force and effect, Infrico will repair or replace, at Infrico’s option, that part of the Equipment that has become defective. Infrico will cover labor cost within (2) two years from the Warranty Commencement date or (27) months from shipment date, whichever occurs first.
  • Page 22 User to Infrico within (30) days after the date the User discovered, or should have discovered, the claim. In connection with all claims under this Warranty, Infrico will have the right, at its own expense, to have its representatives inspect the Equipment at the User’s premises and to request all of User’s records pertaining to the...
  • Page 23 7. Nobody is authorised to make any other concessions or accept on behalf of the manufacturer any commitment that does not comply with this guarantee. 8. If this warranty certificate is lost or mislaid, you must have express knowledge of it. 9.
  • Page 24 User: _______________________________________________________ Address:_____________________________________ Tel:________________ Postal code Town:_________________________________________________ Distributor:_______________________________________________________ Purchase date:____________________________________________________ Model:_________________________ Serial No:_________________________ Compressor No: __________________________ Seller Signature Purchaser Signature Ask your distributor to fill in: User: _______________________________________________________ Address:_____________________________________ Tel:________________ Postal code Town:_________________________________________________ Distributor:_______________________________________________________ Purchase date:____________________________________________________ Model:_________________________ Serial No:_________________________ Compressor No: __________________________ Seller Signature Purchaser Signature...
  • Page 25 Infrico USA, Corp. 1409 N.W. 84th Avenue Doral, Florida 33126 1.305.777.9599 office 1.305.777.9598 fax sales@infrico.com www.infrico.us...
