Infrico Lab Care Plus ULF70086 Service Manual page 33

D09 0
D10 0
D11 0
D12 0
D13 240
PARAM. DEFECT MIN.
S01 0
S02 3
S03 20
S04 24
S05 1
-10 10 ºC/ºF Chamber probe offset
-10 10 ºC/ºF Evaporator probe offset
-10 10 ºC/ºF Condenser probe offset
-10 10 ºC/ºF Differential product sounding
0 300 Seg Delay alarms failure tension
MAX. M.U.
ways of beginning of defrost
1 = MANUAL - defrost initial by means of the keyboard
through menu "defrost"
2 = BY INTERVALS - PER TIME - defrost begins each S04
running hours.
4 = BY INTERVALS - BY the OPERATION OF the COMPRESSOR -
defrost begins each S04 running hours of compressor
8 = 1 HOUR AFTER the STARTING - defrost begins 1 hour after
the ignition of apparatus
128 = ADAPTIVE = - defrost begins by time intervals,
depending on each case, according to the duration of the
ignited compressor or the temperature of the evaporator
(that is to say: defrost begins when the operating time of the
0 25 ? compressor with the evaporator to a T< exceeds the value fit
with the S08 parameter) the recorder data eliminate when
the device is dull, them alarm of high temperature or
sounding error takes place.
MULTIPLE. - more types of desescarche of form can be given
synchronizes by means of the configuration of the parameter
with a given value adding the values of each type of
desescarche (ej. MANUAL and PER TIME → S01 = 1 + 2 = 3)
PROTECTION OF TIME - if a cycle of defrost does not begin
within 72 hours from the previous one, is forced defrost of
protection.
If the sounding of the evaporator is present (C07=1) a cycle of
defrost it begins single when the temperature of the
evaporator is minor who S02-3ºC
-10 30 ºC/ºF Defrost end temperature
1 300 min Maximum defrost duration
1 48 h Interval between two defrosts
0 2 --- Defrost typology
Service Manual and Warranty
ALARMS
32
