ASSEMBLY INSTRUCTIONS
ASSEMBLY
INSTRUCTIONS
The assembly of the table frame to be made in accordance with this manual.
Changes to the table frame or improper use may affect the safety, function, and life of your product.
This manual is for all sit-stand tables from the series.
Due to different models or types, pictures may vary.
ASSEMBLY OVERVIEW
1. Fasten the top support onto the table top
2. Assemble the beam and column to the top support
3. Assemble the foot to the column
4. Fasten the table frame onto the table top
5. Fasten the control box and handswitch to the table top
6. Connect the motor cables to the control box
7. Connect the handswitch (HS) cable to the control box
8. Connect the supplied power cord (AC) to the control box
9. Attach all cables to the table frame or on the underside
of the table top
DO NOT remove the foam surrounding the motor.
If you have any difficulty assembling this unit, or need to order
replacement parts, please contact our Customer Service department.
Use the parts diagrams on page 3-6 as a reference.
