TROUBLESHOOTING
ACOUSTIC CODES
The controller, as soon as it is supplied electric power, can give the user information about the current system
status by means of its integrated relay
# OF DOUBLE
WHEN
CLICK SOUNDS
Supply of electrical power
1
(Dependent on configuration)
1
Up key pressed
1
Lower blockade detected
1
Lower blockade detected
2
Set container or shelf stop
3
First movement after sensor out
3
First movement after sensor reinserted
4
Delete container or shelf stop
6
Container stop or shelf stop too near in the middle
7
Motor cable pulled or missing
7
Table moves at an angle
If it is not possible to resolve an error as described, disconnect the power cord, wait a few minutes and reset the table again.
If the error still occurs, remove the table from the power source and contact customer service.
(Error Code list is valid from firmware 1.7.5 and higher)
.
19
STATUS INFORMATION
Normal Operation: The system is functioning without any problems.
Faulty Operation: The controller does not have any firmware: only 1
click sounds
Reset: Initialization movement is required
Reset: Table has reached the Reset position during the initialization
movement. The key can be released
Reset: Initialization movement has ended;
pressed. Release the key
Confirmation: The position was successfully saved
Caution: A previously detected sensor has been removed. Normal
operation can continue.
Note: A sensor was reconnected after a previously detected sensor
had been removed. Normal operation can continue.
Confirmation: The position was successfully deleted.
Warning: An attempt is being made to set the container stop or shelf
stop too near the middle of the total stroke
Warning: Motor cable absent when connecting to the mains, or has
been disconnected during operation. Connect the missing motor cable
with the controller.
Warning: Slanted position of the table has become too big. Carry out
an initialization movement.
User Guide
key continues to be
