TROUBLESHOOTING
VISUAL CODES
Visual codes can only be used with using handswitch models with a display.
DISPLAY DESCRIPTION
The key on the handswitch
C53
is stuck
C81
Voltage too small
C82
Voltage is too high
No columns connected when the
C84
controller is switched on
Number of columns does not
C85
match the current configuration
REF
Initialization run is carried out.
System protection/ system
pause.
SP
The powering-on duration of the
system was exceeded.
COL
Collision detected
CAL
Sensor calibrated
001-999
The table moves; height display
-
REMEDY
Replace handswitch.
Can occur after disconnecting the
power cord.
Main defective, replace controller.
Main defective, replace controller
First connect the desired number
of columns and handswitches and
use the F3 menu to restore the
factory settings
Check the motor cables or use
the F3 menu to restore the factory
settings
Perform the initialization run to the
lowest block position..
Wait until the controller has cooled
and the display SP turns off. Then,
the movement duration of 17
seconds is cleared. Only after 18
minutes does the table move again
for a full 2 minutes.
ATTENTION: The calculation of the
powering on duration is performed
even if there is no mains voltage
present.
Remove the hindrance.
Leave table alone
21
DISPLAY AFTER
TROUBLESHOOTING
001-999 Normal height display
001-999 Normal height display
C38 An initialization run is required
C38 An initialization run is required
C38 An initialization run is required
C38 An initialization run is required
001-999 Normal height display
001-999 Normal height display
001-999 Normal height display after moving off in one
direction
001-999 Normal height display
