OPERATION INFORMATION
User Guide
OPERATION
INFORMATION
INITIALIZATION/RESET
The desk must be initialized/reset after any of the following:
- After assembly
- After disconnection from the power supply
- After any impact on the table top.
To initialize/reset, move the table to the lowest position by pressing the DOWN button on the handswitch until
the columns reach the lowest position. Press the DOWN button again until the table moves slightly down to the
machine zero point and back up to the operation zero point. Release the DOWN button. If the button is released
too soon, the table legs will not move up. Repeat the reset process.
The control box is programmed with a parameter file which controls the table legs' lower and upper travel limits.
Under no circumstance should a control box from one table be moved to another.
NORMAL HANDSWITCH OPERATION
(for all handswitch types)
By pressing the UP or DOWN buttons, the table will move up or down to the desired position. Once the
desired position is reached, let go of the UP or DOWN button. The table legs will stop once they reach
the lower or upper height limits.
PROGRAMMABLE HANDSWITCH OPERATION
(optional)
This programmable handswitch is equipped with
a display for showing the current table height in
Centimeters or inches.
The handswitch also will display an error code if an error is
detected by the control box. When an error is detected, the
display will show an error code "EXX," instead of the current
table height. To resolve the error, see the Troubleshooting Section of this guide.
The programmable handswitch also has the ability to save up to four different height positions.
CHANGE THE HEIGHT UNIT
(inches or centimeters)
The handswitch can display the table height in either centimeters or inches. With the help of the F1 menus, the
unit of measure can be changed.
To change the unit of measure, follow these steps:
1. Press and hold the (Center/---- button) until "F" appears
2. Using the UP button cycle through the menu for "F1" and press the (Center/---- button)
3. Choose between "I" for inches or "C" for centimeters and press the (Center/---- button) to select.
15
