OPERATION INFORMATION
User Guide
SHELF AND CONTAINER STOPS
Container and shelf stops are safety positions that cannot be run over during normal operations, so that collisions
with known, permanently present hindrances can be prevented. The container stop limits the movement height
downwards (minimum height) and the shelf stop limits the movement height of the table upwards (maximum
height). If an attempt is made to set the container stop or shelf stop too close to the middle, the controller signals
this with 6 quiet click sounds. Note: This function is configuration-dependent and is not available with every
controller. With the additional stops, the safety of the table system can be increased, in that the possible
movement path is restricted.
SET UP SHELF AND CONTAINER STOPS
Move the table using the arrow keys into the desired position. Press both arrow keys at the same time.
The controller confirms with a quiet, double-click. The absence of this signal means that setting is possibly
not permitted.
DELETE THE CONTAINER STOP
Keep the down arrow key pressed. The table stops automatically upon reaching the container stop.
Press both the arrow keys at the same time. The controller confirms with a quiet, double-click.
DELETE THE SHELF STOP
Keep the up arrow key pressed. The table stops automatically upon reaching the container stop. Press both the
arrow keys at the same time. The controller confirms with a quiet, double-click.
WARNING:
With an initialization movement prompted by the controller, the reset position is always
approached directly. Any container stop or safety stop that is present is ignored.
First, remove all hindrances below the table and pay heed to the increased risk of injury.
Only trained personnel should carry out setting and deletion of container and shelf stops. There is a danger of
injury from wrong setting or removal of the Stop positions, and a danger of the table getting destroyed.
