Field Controls SWG-3 Product Manual page 45

CHIMNEY TOP DRAFT INDUCER
FOR WOOD/GAS/COAL FIREPLACES
INDUCER SIZE VOLTS
8" TYPE C
1 15
10" TYPE C
1 15
13" TYPE C
1 15
MODEL
8" C DRAFT INDUCER
10" C DRAFT INDUCER
13" C DRAFT INDUCER
FLUE SENTINEL TERMINATION CAP
The Flue Sentinel Termination Cap is designed to improve air flow
performance by preventing downdrafts and wind interference. It also
keeps rain, snow and animals from entering the flue. It is specially
designed to work with our flue dampers, providing full clearance for
damper blade travel.
FEATURES
• 304 Stainless steel construction
• Four sizes - 8", 10", 12", 14"
• Heavy duty
A
B
C
44
SPECIFICATIONS
MOTOR INFORMATION
AMPS WATTS HZ
.81 57 60
3.75 252 60
3.75 252 60
DIMENSIONS
DIMENSIONS (INCHES)
A B C
7 15 ⁄16 3 3 ⁄8
16
3 3 ⁄8
10 16
13 16 3
8" TERMINATION CAP
10" TERMINATION CAP
12" TERMINATION CAP
14" TERMINATION CAP
MAX. HEARTH
RPMS VOLTS
OPENING
1550 7 sq. ft. 1 15
1050 12 sq. ft. 1 15
1050 30 sq. ft. 1 15
MAX. HEARTH
OPENING
D
14 3 ⁄4
7 sq. ft.
14 3 ⁄4
12 sq. ft.
14 3 ⁄4
30 sq. ft.
FS TERMINATION CAP DIMENSIONS
MODEL
A
12.75
14.75
20.75
23
Customer Service:
SPEED CONTROL
AMPS HZ
5 60
5 60
5 60
TERMINATION CAP
DIMENSIONS (INCHES)
B C
7.38 7.95
7.76 9.95
1 1.20 1 1.95
1 1.83 13.95
252.522.3031
