COMBUSTION AIR UNIT
FOR GAS FIREPLACES
COMBUSTION AIR
The Combustion Air Damper or Fresh Air Damper works with
an Intake Air Hood to provide a reliable source of fresh air for
combustion directly to the firebox. This is ideal for fireplaces
not located on or near an exterior wall. This sealed damper
opens when the gas logs are turned on, allowing fresh air to
enter the firebox as needed for combustion. When the logs are
turned off, the damper closes.
FEATURES
• Stainless steel housing and damper
• Ultra-reliable motor
• Power open/power close
• Super-tight seal
Flue
Sentinel
®
Automatic
Flue Damper
shown with optional
termination cap
Open Hearth
MODEL PRODUCT
FAD-4 FRESH AIR DAMPER
FAD-5
FRESH AIR DAMPER
FAD-6
FRESH AIR DAMPER
FAD-7
FRESH AIR DAMPER
FAD-8
FRESH AIR DAMPER
FAD-10
FRESH AIR DAMPER
FAD-14
FRESH AIR DAMPER
FAD-16 FRESH AIR DAMPER
FAD-18 FRESH AIR DAMPER
FAD-20 FRESH AIR DAMPER
48
BENEFITS
• Delivers combustion air automatically, on demand
• Helps reduce heating and cooling costs
HOW IT WORKS
When there is a call for fire, the damper opens and
Combustion
Air Damper
allows the fire to start. Outside air is channeled through
the ductwork directly into the firebox for combustion air.
When the fire is turned off, the damper closes.
DESCRIPTION
POWER OPEN/CLOSE, FITS 4" DUCT OR PIPE
POWER OPEN/CLOSE, FITS 5" DUCT OR PIPE
POWER OPEN/CLOSE, FITS 6" DUCT OR PIPE
POWER OPEN/CLOSE, FITS 7" DUCT OR PIPE
POWER OPEN/CLOSE, FITS 8" DUCT OR PIPE
POWER OPEN/CLOSE, FITS 10" DUCT OR PIPE
POWER OPEN/CLOSE, FITS 14" DUCT OR PIPE
POWER OPEN/CLOSE, FITS 16" DUCT OR PIPE
POWER OPEN/CLOSE, FITS 18" DUCT OR PIPE
POWER OPEN/CLOSE, FITS 20" DUCT OR PIPE
Combustion
Air Damper
Intake Air Hood
VOLTAGE
24
24
24
24
24
24
24
24
24
24
Customer Service: 252.522.3031
AMPS WATTS
– 3
– 3
– 3
– 3
– 3
– 3
– 3
– 3
– 3
– 3
