OPEN HEARTH
THE FLUE SENTINEL
A SEALED HEARTH WITH ALL THE BENEFITS OF AN OPEN HEARTH.
Flue Sentinel turns the hearth, firebox, and chimney into a Healthy Hearth System™ . A healthy hearth with Flue Sentinel operates
®
safely and efficiently without negatively impacting the home's overall efficiency and design. Flue Sentinel systems have sufficient
draft to ensure that exhaust goes up the chimney, a sealed damper to automatically open and close the vent or chimney, and
safety interlocks to prove safe operation every time the fire is lit.
A direct source for combustion air can be included to provide a truly "sealed" system. The Fresh Air Damper and vent damper
open in unison and the hearth operates as a sealed system. The illustration above demonstrates the primary requirements of a
healthy hearth.
38
®
HEALTHY HEARTH
Flue Sentinel Damper
®
Effectively closes the chimney when
the hearth is not in use, preventing
heat loss and downdrafts.
OR
Flue Sentinel Chimney Fan
®
with Automatic Damper
Fan provides constant flow of air
to safely exhaust fumes. Damper
closes when not in use to
conserve energy.
Hearth Combustion Air
A reliable, dedicated source of
combustion air keeps the fire burning
efficiently without taking air from
within the house.
