COMBUSTION AIR SYSTEMS
COMMERCIAL
FAN-IN-A-DRUM
STARKAP
FAN-IN-A-DRUM ASSEMBLY
®
26
CAS-6 AND CAS-7
The Fan-in-a-Drum
air into the mechanical room, boiler room, or furnace location to overcome a
confined space or inadequate air supply. CAS 6 & 7 are dual volt units for oil
or gas applications.
HOW THE CAS-6 AND CAS-7 WORK
®
When the thermostat calls for heat, the Fan-in-a-Drum® engages and begins
drawing air into the structure. When air flow is established, the pressure switch
closes. The CAS sends a signal to the appliance, allowing the burner to fire. The
Fan-in-a-Drum® diffuses the outside air into the room near the burner to ensure
adequate air for efficient combustion.
MAX. EQUIVALENT LENGTH OF PIPE, INCLUDING STARKAP
CAS-6 OIL
(GPH)
3
3.25
3.5
® 3.75
4
4.25
4.5
4.75
5
5.25
5.75
6
6.50
CAS-7 OIL
(GPH)
6
6.5
7
Can also be
7.5
installed
8.25
through
9
the wall
9.75
10.5
1 1.25
12
12.75
12.88
is a commercial product designed to deliver combustion
®
CAS-6 GAS
8" DUCT
(BTU/HR)
420,000 410
455,000 344
490,000 291
525,000 249
560,000 214
595,000 185
630,000 160
665,000 139
700,000 121
735,000 105
805,000 79
840,000 58
910,000 49
CAS-7 GAS
10" DUCT
(BTU/HR)
840,000 469
910,000 381
980,000 31 1
1,050,000 256
1,155,000 191
1,260,000 142
1,365,000 104
1,470,000 74
1,575,000 51
1,680,000 31
1,785,000 15
1,803,000 13
Customer Service:
®
10" DUCT 12" DUCT
1253 31 19
1051 2616
890 2217
760 1893
653 1627
584 1405
489 1217
424 1057
369 919
321 800
241 601
176 519
151 377
12" DUCT 14" DUCT
1 167 2523
948 2050
776 1678
637 1378
476 1029
354 766
260 563
186 403
127 274
78 207
39 1 14
33 72
