VENT RISER
SIZING THE VENT RISER
SUB-GRADE VENTING JUST GOT EASIER!
For basement installations where a window well must be
used, or in installations where the vent terminal cannot be
mounted to maintain the minimum 12" clearance above
grade, use a Field Vent Riser™
FEATURES
• Ensures the vent termination is above grade and in
compliance with codes
• Perfect for basement installations where a window
well must be used or when a vent terminal cannot
be mounted to maintain a minimum 12" clearance
above grade
• Stainless steel construction
• Combustion air connection for use with CAS Boot
rotates 360° for easier installation
MODEL A
42 1 ⁄16"
CV-4VR
42 1 ⁄16"
CV-5VR
MODEL VOLTS
CV-4VR 1 15
CV-5VR 1 15
10
™
DIMENSIONS
B C D
33 1 ⁄2" 17 3 ⁄4"
9"
32 1 ⁄4" 20 3 ⁄8" 9 5 ⁄8"
SPECIFICATIONS
HZ AMPS WATTS
60 1.7 138
60 1.3 144
E F G
6 3 ⁄8" 10 1 ⁄2"
44"
6 7 ⁄8"
44" 10"
RPM THERMAL PROTECTION
3000 YES
3100 YES
Customer Service:
H
12 1 ⁄2"
12 7 ⁄8"
252.522.3031
