Maximal Access Power/Controllers distribute and switch power to access control systems and accessories. They

convert a 115VAC 60Hz input into sixteen (16) independently controlled 12VDC or 24VDC fuse protected outputs.

These Fail-Safe/Fail-Secure power outputs may be converted to dry form "C" contacts. The outputs are activated

by an open collector sink or normally open (NO) dry trigger input from an Access Control System, Keypad, Push

Button, REX PIR, etc. Units will route power to a variety of access control hardware devices including: Mag Locks,

Electric Strikes, Magnetic Door Holders, etc. The FACP Interface enables Emergency Egress, Alarm Monitoring, or

may be used to trigger other auxiliary devices. The fire alarm disconnect feature is individually selectable for any or

all of the sixteen (16) outputs. All interconnecting equipment must be UL Listed.

Altronix

Output Voltage Options

Model

Power Supply 1 Power Supply 2

Number

AL400ULXB2

12VDC @ 3.5A

Maximal11

12VDC @ 2.7A

24VDC @ 3.5A

AL600ULXB

12VDC @ 5.5A

Maximal33

12VDC @ 5.7A

24VDC @ 5.5A

AL1012ULXB

Maximal55

12VDC @ 9.5A

AL1012ULXB

Maximal75

12VDC @ 9.5A

AL1024ULXB2

Maximal77

24VDC @ 9.7A

*Maximal11 outputs are power-limited.

**ANSI/UL 294 7th Ed. Access Control Performance Levels:

Destructive Attack - I; Endurance - I; Line Security - I; Stand-by Power - I, IV.

Maximal11/33/55/75/77 (Fused) Series Installation Guide
