MaxFit E Series
Single Power Supply
Expandable Power Systems
Models Include:
MaxFit3E
- 12VDC/24VDC @ 6A.
MaxFit5E
- 12VDC @ 10A.
MaxFit7E
- 24VDC @ 10A.
Installation Guide
Rev. 021122
Installing Company: _______________ Service Rep. Name: __________________________________
Address: _____________________________________________ Phone #: __________________
More than just power.
TM
Advertisement
Table of Contents
Related Manuals for Altronix MAXIMAL FIT MaxFit E Series
Summary of Contents for Altronix MAXIMAL FIT MaxFit E Series
- Page 1 MaxFit E Series Single Power Supply Expandable Power Systems Models Include: MaxFit3E - 12VDC/24VDC @ 6A. MaxFit5E - 12VDC @ 10A. MaxFit7E - 24VDC @ 10A. Installation Guide Rev. 021122 More than just power. Installing Company: _______________ Service Rep. Name: __________________________________ Address: _____________________________________________ Phone #: __________________...
- Page 2 MaxFit E Series Overview: Altronix MaxFit Expandable Power System provide system designers and installers with maximum power choices and the highest levels of versatility. They provide 12VDC or 24VDC. The suit of features includes AC fail, low battery and battery presence monitoring. All interconnecting equipment must be UL Listed. MaxFit enclosure offers ample room for expanding access control systems and accommodates up to four (4) 12VDC/12AH batteries.
-
Page 3: Maintenance
4. Measure output voltage before connecting devices. This helps avoiding potential damage. 5. Connect devices or Altronix sub-assembly modules to be powered to the terminals marked [– DC +] (Fig. 1h, pg. 4). Refer to page 2 for non power-limited applications. - Page 4 Fig. 1 - ULXB Board Configuration OFF --- 24V ON --- 12V 1d** 1c*** 5A 250V BAT FAIL NC C NO NC C NO AC FAIL MaxFit3E Power Supply Board Output Voltage Settings: Fig. 2 OFF - 24V Fig. 2a ON - 12V OFF - 24V ON - 12V...
-
Page 5: Power Supply Board Led Diagnostics
Power Supply Board LED Diagnostics: Power Supply Status Red (DC) Green (AC) Normal operating condition. Loss of AC. Stand-by battery is supplying power. No DC output. Short circuit or thermal overload condition. No DC output. Loss of AC. Discharged battery. Red (Bat) Battery Status Normal operating condition. -
Page 6: Nec Power-Limited Wiring Requirements
NEC Power-Limited Wiring Requirements: Power-limited and non power-limited circuit wiring must remain separated in the cabinet. All power-limited circuit wiring must remain at least 0.25” away from any non power-limited circuit wiring. Furthermore, all power-limited circuit wiring and non power-limited circuit wiring must enter and exit the cabinet through different conduits. One such example of this is shown below. - Page 7 Notes: - 7 - MaxiFit3E/MaxFit5E/MaxFit7E Expandable Power Systems Installation Guide...
- Page 8 1.25” (31.8mm) 1.25” (31.8mm) 7.00” (177.8mm) 7.00” (177.8mm) Altronix is not responsible for any typographical errors. –––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––– 140 58th Street, Brooklyn, New York 11220 USA | phone: 718-567-8181 | fax: 718-567-9056 website: www.altronix.com | e-mail: info@altronix.com | Lifetime Warranty MEMBER...
