Maximal FV Series
Single Power Supply
Access Power Controllers (fused)
Models Include:
Maximal3FV
- 12VDC @ 4.6A or 24VDC @ 5.2A.
- Sixteen (16) fuse protected non power-limited outputs.
Maximal5FV
- 12VDC @ 8.6A.
- Sixteen (16) fuse protected non power-limited outputs.
Maximal7FV
- 24VDC @ 9.2A.
- Sixteen (16) fuse protected non power-limited outputs.
Installation Guide
Rev. SFFV031115
Installing Company: _______________ Service Rep. Name: __________________________________
Address: _____________________________________________ Phone #: __________________
More than just power.
TM
Advertisement
Table of Contents
Related Manuals for Altronix Maximal FV Series
Summary of Contents for Altronix Maximal FV Series
- Page 1 Maximal FV Series Single Power Supply Access Power Controllers (fused) Models Include: Maximal3FV - 12VDC @ 4.6A or 24VDC @ 5.2A. - Sixteen (16) fuse protected non power-limited outputs. Maximal5FV - 12VDC @ 8.6A. - Sixteen (16) fuse protected non power-limited outputs.
-
Page 2: Table Of Contents
Maximal FV Series Configuration Chart ........ -
Page 3: Maximal Fv Series Overview
Maximal FV Series Overview: Altronix Maximal FV Access Power/Controllers distribute and switch power to access control systems and acces- sories. They convert a 220VAC (working range 198VAC - 256VAC), 50/60Hz input into sixteen (16) independently controlled 12VDC or 24VDC fuse protected outputs. These Fail-Safe/Fail-Secure power outputs may be converted to dry form “C”... -
Page 4: Eflow Power Supply/Charger
Maximal FV Series Features: eFlow Power Supply/Charger: • Input: 220VAC (working range 198VAC - 256VAC), 50/60Hz. • For output voltage and supply current refer to Maximal FV series Configuration Chart, pg. 3. • Auxiliary output rated @ 1A (unswitched). • Overvoltage Protection. - Page 5 (a) Fail-Safe Switched Power outputs: For Fail-Safe operation connect the positive (+) input of the access control devices to terminal marked [NC]. Connect the negative (–) input of the access control devices to terminal marked [COM]. (b) Fail-Secure Switched Power outputs: For Fail-Secure operation connect the positive (+) input of the access control devices to terminal marked [NO].
-
Page 6: Maintenance
14. Installation of tamper switch (Fig. 3b, pg. 9): Mount UL Listed tamper switch (Altronix Model TS112 or equivalent) at the top of the enclosure. Slide the tamper switch bracket onto the edge of the enclosure approximately 2” from the right side (Fig. 3b, pg. 9). -
Page 7: Access Power Controller Terminal Identification
Power Supply Board Terminal Identification: Terminal Legend Function/Description Connect 220VAC 50/60Hz to these terminals: L to hot, N to neutral. L, N Do not use terminal marked [G] + DC – Factory connected to ACM8 board. Trigger EOL Fire Alarm Interface trigger input from a short or FACP. Trigger inputs can be normally Supervised open, normally closed from an FACP output circuit (Fig. -
Page 8: Power Supply Board Output Voltage Settings
Power Supply Board Output Voltage Settings: Fig. 1 - Maximal3FV Power Supply Board Fig. 1a OFF - 24V ON - 12V Access Power Controller Typical Application Diagram (for each ACM8): Fig. 2 Fig. 2a Intact = Dry Input Normally Open (N.O.) Cut = Wet Input Door Releasing FACP... -
Page 9: Maximal Fv Battery Hookup And Tamper Switch Installation
Fig. 3 - Maximal3FV, Maximal5FV, and Maximal7FV Tamper Switch Ground OFF - 24V ON - 12V Power Supply Board AC DC NC C NO NC C NO TRIGGER +AUX- AC FAIL BAT FAIL SUPERVISED RESET Line Neutral Input 220VAC, 50/60Hz CAUTION: When power supply board is set for 12VDC Fig. -
Page 10: Nec Power-Limited Wiring Requirements
NEC Power-Limited Wiring Requirements: Power-limited and non power-limited circuit wiring must remain separated in the cabinet. All power-limited circuit wiring must remain at least 0.25” away from any non power-limited circuit wiring. Furthermore, all power-limited circuit wiring and non power-limited circuit wiring must enter and exit the cabinet through different conduits. One such example of this is shown below. -
Page 11: Facp/Optional Power Supply Hook-Up Diagrams
FACP Hook-Up Diagrams: Fig. 5 Polarity reversal input from FACP signaling circuit output (polarity is referenced in alarm condition): JUMPER FACP FACP OUTPUT EOL FROM FACP OUTPUT CIRCUIT Fig. 6 Normally Open: Non-Latching FACP Fig. 7 Normally Open FACP Latching trigger trigger input: input with reset (This output has not been evaluated by UL):... -
Page 12: Enclosure Dimensions
(21.6mm) 4” (101.6mm) 2” (50.8mm) 19” (482.6mm) Altronix is not responsible for any typographical errors. –––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––– 140 58th Street, Brooklyn, New York 11220 USA | phone: 718-567-8181 | fax: 718-567-9056 website: www.altronix.com | e-mail: info@altronix.com | Lifetime Warranty IIMaximal3FV/5FV/7FV Series...
