2.2.2. Rear view
DVI-OPT-RX220-Pro
1
DVI-OPT-RX220-ST-Pro
AC connector
1
DVI outputs
2
Alarm outputs
3
Serial port
4
Break-out connector
5
Neutrik connector
6
7
Power selector
ST connector
8
Page 14 / 57
AC connector
5
Break-out connector
Power selector
7
AC connector
1
Standard IEC power connector. Accepts 100 to 240 Volts, 50 or
60 Hz power sources.
29 pole DVI-I connector, however only digital pins are internally
connected. The resolution and pixel clock frequency are the
same on both DVI connectors; no internal scaling or conversion
is applied to the signal.
DVI signal detection and laser detection signals with ground
reference are available on a three-pole Phoenix connector. See
section
9-pole
communication. See section
The break-out LC connector is internally connected to output B
of the Neutrik connector with a multimode 50/125 fiber optical
patch cable. The user can connect the signal of another fiber
optical transmitter to pass it through a double-core Neutrik fiber
optical cable. See section
Neutrik NO2-4FDW type LC duplex connector. Carrying the
signals of up to two transmitters. See section
and section
The receiver's power source can be selected with this switch. In
position "I" the receiver unit is powered with its own built-in power
supply. In position "II" the receiver unit is powered through hybrid
fiber cable. See section
ST fiber optical connector. Carrying the signals between
transmitter and receiver. See section
information.
6
DVI outputs
ST connector
8
DVI outputs
2.3.4
on page
16
D-SUB
female
4.3.2
on page 22 for more information.
4.2.2
Neutrik connector
2
Alarm outputs
Serial port
2
Alarm outputs
for more information.
connector
for
2.3.3
on page 16.
1.6
on page
10
for typical application.
2.3.1
on page
21
for more information.
2.3.1
on page
Section 2. Controls and connections
Serial port
4
3
4
3
serial
RS-232
on page
15
15
for more
