1.5. Receiver features

 Supports all HDTV resolutions – 720p, 1080i, 1080p etc. without HDCP encoding. Unencrypted
 Single Fiber Technology – All of the high-speed TMDS data lanes are transmitted using only
1.65 Gb/s channel transmission – Extends any DVI single link signal between 25 and 165

 Two identical DVI outputs – A built-in distribution amplifier transmits the signal coming from fiber
 Laser Detect LED – Bi-color (green and red) LED indicates when a laser beam is detected on
 DVI Signal Present and Monitor Connected LEDs – Three LEDs indicate when a valid DVI
 Alarm outputs – Two TTL level alarm outputs are provided for DVI signal detection and laser
 Break-out LC connector (only on DVI-OPT-RX220-Pro) – A break-out LC fiber optical
 RS-232 control – Status information, parameter settings and firmware upgrade via serial port is
 Pixel Accurate Reclocking (removes jitter caused by long cables) - Each output has a clean,
 Built-in universal power supply – The receiver is equipped with a built-in universal power
 Remote power receive (only on DVI-OPT-RX220-Pro) – Switchable self or remote power
Section 1. Introduction
signals up to 165 MHz pixel clock frequency - regardless of the resolution - are
passed through.
one multimode 50/125 fiber optical cable.
MHz TMDS clock frequency conforming to DVI 1.0 standard.
B of the Neutrik connector to two DVI output connectors.
input B of the Neutrik connector.
signal is detected, the display devices are connected and they are sending Hot
Plug signals.
detection. A ground reference signal is also provided.
connector allows the users to receive the signal of two optical transmitters in one
Neutrik opticalCON Duo cable, that has two fiber cores. See section
10 for typical application.
available.
jitter free signal, eliminating signal instability and distortion caused by long cables
or connector reflections.
supply, which accepts AC voltages from 100 to 240 Volts with 50 or 60 Hz line
frequency.
supply. Transmitter can send power to receiver if special hybrid fiber cable is used
(type Neutrik 2M-4S75).
DVI-OPT-TX220-Pro, DVI-OPT-RX220-Pro
User's Manual
1.6 on page
Page 9 / 57
