- Page 1 DVI-OPT-TX220-Pro DVI-OPT-TX220-ST-Pro DVI-OPT-RX220-Pro DVI-OPT-RX220-ST-Pro User’s Manual...
-
Page 3: Safety Instructions
DVI-OPT-TX220-Pro, DVI-OPT-RX220-Pro User’s Manual SAFETY INSTRUCTIONS Class I apparatus construction. This equipment must be used with a main power system with a protective earth connection. The third (earth) pin is a safety feature, do not bypass or disable it. This equipment should be operated only from the power source indicated on the product. -
Page 4: Declaration Of Conformity
DECLARATION OF CONFORMITY Lightware Kft. 1071 Budapest Peterdy str. 15 HUNGARY as manufacturer declare, that the products DVI-OPT-TX220-Pro DVI-OPT-RX220-Pro DVI-OPT-TX220-ST-Pro DVI-OPT-RX220-ST-Pro (Computer Monitor Extender) in accordance with the EMC Directive 2004/108/EC and the Low Voltage Directive 2006/95/EEC are in conformity with the following standards: EMI/EMC .... -
Page 5: Table Of Contents
5.3.6. Deleting EDID ......................26 5.3.7. Laser enabling ......................27 5.3.8. Factory reset ......................27 5.3.9. Device information ....................27 SOFTWARE CONTROL – USING LIGHTWARE DEVICE CONTROLLER (LDC) ....28 6.1. OS ............28 TEPS OF THE INSTALLATION IN CASE OF INDOWS 6.2. - Page 6 6.4..................32 STABLISHING THE CONNECTION 6.5. I/O P ....................32 ARAMETERS MENU 6.6. EDID ) ....................33 MENU TRANSMITTER 6.6.1. Sources and Destinations ..................33 6.6.2. Changing the emulated EDID at the input .............. 34 6.6.3. Exporting an EDID ....................35 6.6.4.
-
Page 7: Introduction
User’s Manual 1. Introduction Thank you for choosing Lightware DVI-OPT extenders. The extenders are capable of transmitting Single Link DVI signals over fiber optical cable to a distance of up to 2500 meters with up to 1920x1200@60Hz resolution using a single OM3e type fiber cable. -
Page 8: Transmitter Features
HUM effects. Advanced EDID Management – User can emulate any EDID on the DVI-OPT-TX220-Pro’s input, read out and store any monitor's EDID (attached to Local Monitor Output) in 49 internal memory locations. -
Page 9: Receiver Features
DVI-OPT-TX220-Pro, DVI-OPT-RX220-Pro User’s Manual 1.5. Receiver features Supports all HDTV resolutions – 720p, 1080i, 1080p etc. without HDCP encoding. Unencrypted signals up to 165 MHz pixel clock frequency - regardless of the resolution - are passed through. Single Fiber Technology – All of the high-speed TMDS data lanes are transmitted using only one multimode 50/125 fiber optical cable. -
Page 10: Applications
Ground loop isolation Multi-room video control Professional AV systems, conference rooms Rental and Staging Digital signage Info: For the compatible Lightware products please see the compatibility table on www.lightware.eu. Page 10 / 57 Section 1. Introduction... -
Page 11: Controls And Connections
DVI-OPT-TX220-Pro, DVI-OPT-RX220-Pro User’s Manual 2. Controls and connections 2.1. Transmitters 2.1.1. Front view Info: The front view of DVI-OPT-TX220-Pro and DVI-OPT-TX220-ST-Pro is almost the same; the only difference is the type designation. Power LED Menu display Menu navigation Laser LED... -
Page 12: Rear View
2.1.2. Rear view DVI-OPT-TX220-Pro AC connector Serial port Break-out connector Neutrik connector DVI input Monitor output Laser LED DVI-OPT-TX220-ST-Pro AC connector Serial port ST connector DVI input Monitor output Laser LED AC connector Standard IEC power connector. Accepts 100 to 240 Volts, 50 or 60 Hz power sources. -
Page 13: Receivers
DVI-OPT-TX220-Pro, DVI-OPT-RX220-Pro User’s Manual 2.2. Receivers 2.2.1. Front view Info: The front view of DVI-OPT-RX220-Pro and DVI-OPT-RX220-ST-Pro is almost the same; the only difference is the type designation. Power LED Laser LED Signal LED Monitor LEDs Power LED Green LED indicates if the device is powered on. It does not indicate whether the device is operating properly. -
Page 14: Rear View
2.2.2. Rear view DVI-OPT-RX220-Pro AC connector Serial port Break-out connector Neutrik connector Power selector DVI outputs Alarm outputs DVI-OPT-RX220-ST-Pro AC connector ST connector Serial port DVI outputs Alarm outputs AC connector Standard IEC power connector. Accepts 100 to 240 Volts, 50 or 60 Hz power sources. -
Page 15: Electrical Connections
DVI-OPT-TX220-Pro, DVI-OPT-RX220-Pro User’s Manual 2.3. Electrical connections 2.3.1. Fiber optical connectors Signal Remote power for receiver DC out +15V Remote power for receiver DC out +15V Channel A Channel B Figure 2-1. Neutrik® OpticalCON Duo connector pin assignments ST receptacle LC receptacle Figure 2-2. -
Page 16: Rs-232 Control Port
2.3.3. RS-232 control port Devices can be remote controlled through industry standard 9 pin D-SUB female connector located on the rear panel of the unit. Please use a standard RS-232 Male to Female cable (straight through). Pin nr. RS-232 NC, not connected TX data transmit (output) RX data receive (input) DTR (internally connected to Pin 6) -
Page 17: Technologies
Lightware DVI-OPT-TX220-Pro, a WUXGA (1920x1200) LCD as local monitor, then a DVI-OPT-RX220-Pro connected to an SXGA (1280x1024) projector and an UXGA (1600x1200) monitor. I would like to see the same image on the monitor and the projector. What EDID should I chose on the transmitter?”... -
Page 18: Advanced Edid Management
Problem: „I have changed to a different EDID on the DVI-OPT-TX220-Pro to have a different resolution but nothing happens.” Solution: Some graphics cards and video sources read out the EDID only after power-up and later they don’t sense that EDID has been changed. You need to restart your source to make it read out the EDID again. - Page 19 DVI-OPT-TX220-Pro, DVI-OPT-RX220-Pro User’s Manual The Pixel Accurate Reclocking circuit eliminates the following errors: Intra-pair skew: skew between the + and - wires within a differential wire pair (e.g. Data2- and Data2+). It’s caused by different wire lengths or slightly different wire construction (impedance mismatch) in DVI cable.
-
Page 20: Installation
Step 1. Connect the DVI source (e.g. computer) to the DVI INPUT connector. Step 2. Connect a compatible Lightware fiber receiver unit with a multimode fiber cable to the FIBER OUTPUT connector. Connect an LC optical cable to the “channel A” LC connector, or use a Neutrik OpticalCON Duo cable. -
Page 21: Setting Up The Receiver Unit
Step 1. Connect the DVI display devices to the DVI OUTPUT connectors. Step 2. Connect a compatible Lightware fiber transmitter unit with a multimode fiber cable to the FIBER INPUT connector. Connect an LC optical cable to the “channel B” LC connector, or use a Neutrik OpticalCON Duo cable. -
Page 22: Receiver Unit (Dvi-Opt-Rx220-Pro)
The receiver’s laser sensor gets the signal through “Channel B”. “Channel A” is directly connected to the break-out connector with a fiber optical cable inside the unit. Any optical signal can be transferred through this channel in any direction. DVI-OPT-RX220-PRO DVI-OPT-TX110 Laser sensor DVI-OPT-TX220-Pro MX-DVI-OPT-OB-… Lightware fiber HDMI-OPT-TX200 transmitter MX-HDMI-OPT-OB Neutrik cable... -
Page 23: Operation
D2............Last attached monitor’s EDID (Local Monitor) E1 .................... Emulated EDID (Input) Info: DVI-OPT-TX220-Pro can handle both 128 Byte EDID and 256 Byte extended EDID structures. Info: The attached monitor’s EDID is stored automatically, until a new monitor is attached to the local monitor output. -
Page 24: Front Panel Operations (Transmitter)
MEMORY Resolution MEMORY Resolution 640 x 480 @ 60.0 Hz 1600 x 1200 @ 50.0 Hz 640 x 480 @ 75.0 Hz 1600 x 1200 @ 60.0 Hz 848 x 480 @ 60.0 Hz 1920 x 1200 @ 59.55 Hz 800 x 600 @ 50.0 Hz 1920 x 1200 @ 50.0 Hz 800 x 600 @ 60.30 Hz... -
Page 25: Viewing Emulated Edid
DVI-OPT-TX220-Pro, DVI-OPT-RX220-Pro User’s Manual 5.3.2. Viewing emulated EDID This is the default display in idle state. If needed use EmulatedEDID the left ◄ and right ► buttons to select the 1920x1200@59.55H EMULATED EDID menu. The currently emulated EDID is shown. Three screens toggle automatically showing... -
Page 26: Switching Edid
In this case the source device must be restarted, or powered OFF and ON again. Info: Lightware factory presets have LWR as the manufacturer. 5.3.6. Deleting EDID Step 1. Use the left ◄ and right ► buttons to select the Delete EDID Delete EDID menu. -
Page 27: Laser Enabling
DVI-OPT-TX220-Pro, DVI-OPT-RX220-Pro User’s Manual 5.3.7. Laser enabling Step 1. Use the left ◄ and right ► buttons to select the Laser Enable LASER ENABLE menu. Step 2. Use the up ▲ and down ▼ buttons to change ON/OFF. The selected value will blink. -
Page 28: Software Control - Using Lightware Device Controller (Ldc)
6. Software control – Using Lightware Device Controller (LDC) The extenders can be controlled by a computer using Lightware Device Controller. The software can be installed to a Windows PC or MAC OS X. The application and the User’s manual can be downloaded from www.lightware.eu. After the installation the Windows and the Mac application has the same look and functionality. - Page 29 Step 6. Verify the settings and if they are correct click Install. (If not, click Back and change the setting.) Step 7. After the installation of the last component the Next button is activated. Click on it. Section 6. Software control – Using Lightware Device Controller (LDC) Page 29 / 57...
-
Page 30: Steps Of The Installation In Case Of Mac Os X
Info: This type of the installer is equal with the Normal install in case of Windows This is an updateable version with the same attributes. Section 6. Software control – Using Lightware Device Controller (LDC) Page 30 / 57... -
Page 31: Ldc Upgrade
Step 1. Start the application. The Device Discovery window appears automatically and the program checks the available updates on the Lightware website and opens the update window if the LDC found updates. The current and the update version number can be seen in the top of the window and they are shown in this window even with the snapshot install. -
Page 32: Establishing The Connection
After connecting to the device, this menu appears by default showing the current state of input and output ports. The port bar on the right side shows the available input and output ports. Figure 6-2. I/O Parameters menu Section 6. Software control – Using Lightware Device Controller (LDC) Page 32 / 57... -
Page 33: Edid Menu (Transmitter)
Output1 & 2: Figure 6-3. Input parameters Parameters The factory default settings give good results in most cases. Please consult Lightware support for further information if encountering problems with signal quality. Reload factory defaults Default values are reloaded to the input. -
Page 34: Changing The Emulated Edid At The Input
Info: Power ON/OFF cycle will not affect the emulated EDID or other settings. Info: EDID routing procedure causes a status change, hence it is reported back to the control software within 2-3 seconds. Section 6. Software control – Using Lightware Device Controller (LDC) Page 34 / 57... -
Page 35: Exporting An Edid
Step 3. Press Delete selected button to delete the EDID(s). 6.6.6. EDID Summary window Select an EDID from Source panel and press Info button to display EDID Info summary. Figure 6-5. EDID summary window Section 6. Software control – Using Lightware Device Controller (LDC) Page 35 / 57... -
Page 36: Advanced Edid Editor
6.6.8. Easy EDID Creator Since the above-mentioned advanced editor needs more knowledge about EDID, Lightware introduced a wizard like interface for fast and easy EDID creation. With Lightware Easy EDID Creator, it is possible to create custom EDIDs in four simple steps. -
Page 37: Terminal Menu
If the Autoscroll checkbox is checked, the window is scrolled down automatically when a new row is added. The window can be emptied by pressing the Clear button. Section 6. Software control – Using Lightware Device Controller (LDC) Page 37 / 57... -
Page 38: Settings Menu
Generate report LDC is able to collect information from the extender and save it to a report file. This information package can be sent to Lightware support team when a problem may arise with the extender. Info: When a report is necessary to generate, always let the devices be connected to the extenders, do not disconnect them. -
Page 39: User Preferences Tab
Generate report from file file to the extender. The command file can be generated by Lightware support. This is needed when some special commands has to be used for configuring or troubleshooting. Info: This function is only for special troubleshooting cases. -
Page 40: Programmer's Reference
Format Example → {P_?} Command {P_?} Response (CURRENT●PROTOCOL●= ← (CURRENT PROTOCOL = #1)CrLf ●#<protocol>)CrLf Explanation: The extender communicates with Lightware protocol (#1). 7.1.2. View product type Description: The extender responds its type. Format Example → {i} Command {i} ← (I: DVI-OPT-TX220-PRO)CrLf Response (<PRODUCT_TYPE>)CrLf... -
Page 41: View Installed I/O Board
Format Example → {fc} Command {FC} Response (CF●<DESC>)CrLf ← (CF DVI-OPT-TX220-PRO FW:1.1.8) (CF END)CrLf (CF END) CrLf Explanation: The firmware version of the control panel is 1.1.8. 7.1.7. All port status Description: Shows the actual status of all input and output ports. -
Page 42: Save Edid To User Memory (Learn Edid)
7.2.2. Save EDID to user memory (Learn EDID) Description: Learn EDID to <loc1> from <loc2>. Format Example → {U4:D2} Command {<loc1>:<loc2>} ← Response (E_SW_OK)CrLf (E_SW_OK)CrLf ← (E_S_C) CrLf (E_S_C) CrLf Explanation: EDID from output 2 is saved to user EDID #4. <loc1>... -
Page 43: View Edid Header
DVI-OPT-TX220-Pro, DVI-OPT-RX220-Pro User’s Manual Each number represents the EDID validity state for the corresponding memory location: Value Description “0”’ invalid EDID “1” valid EDID “3” changed EDID “4” deleted EDID Info: If a changed EDID is queried by the {WH} command (see the next section), its value returns to “1”. -
Page 44: Upload Edid Content To A Location
7.2.7. Upload EDID content to a location Description: EDID hex bytes can be written directly to the user programmable memory locations. Sequence Step 1. Prepare the extender to accept EDID bytes to the specified location <loc> with command {WL#<loc>} Step 2. Extender responds that it is ready to accept EDID bytes with (E_L_S)CrLf Step 3. -
Page 45: Restart The Extender
DVI-OPT-TX220-Pro, DVI-OPT-RX220-Pro User’s Manual Legend: Depending on <loc>, one EDID, or all EDIDs in a block can be cleared. <loc> Result Not valid! Factory EDID cannot be deleted. Specified User EDID is deleted. Specified Dynamic EDID is deleted. It will be empty until a new monitor is connected. -
Page 46: Port Status Changed
7.3.2. Port Status Changed Description: This message is sent when any value changes in the response for the {PS} command. The message means that an input or output port’s state has changed e.g. a source or display device is connected or disconnected. Format Example Command none... -
Page 47: Firmware Upgrade
Set to factory defaults Table 8-1. Storage memories 8.1. Install the Bootloader DVI-OPT-TX220-Pro and DVI-OPT-RX220-Pro can be upgraded using Lightware Bootloader from a Windows based PC or Laptop through RS232 connection. Step 1. Run Installer_LW_bootloader_v3_2_9.exe (3_2_9 means the 3-digit software version of the Bootloader). -
Page 48: Upgrade Process
Step 4. After the files have been copied the following message appears: Step 5. To finish the installation process, click on the Close button. Step 6. To run Lightware Bootloader, find the shortcut icon in Start Menu Programs Lightware LW_bootloader_v3_2_9 or on the desktop and double click on it. - Page 49 DVI-OPT-TX220-Pro, DVI-OPT-RX220-Pro User’s Manual Step 5. Click “FIND” Button! Info: Note that you must wait until all the devices on the network completely start up, before pressing FIND button. Figure 8-2. Bootloader searches for devices Step 6. Select the desired device Double click on the desired COM port.
- Page 50 Step 9. Upgrade firmware(s) Click “UPGRADE SELECTED FIRMWARES” button on the left side. A confirmation message appears. After clicking the “YES” button the selected controller is being reprogrammed, with the firmware you selected. If you select a file that doesn’t fit for the selected controller, you will get an information message about which file is wrong.
-
Page 51: Troubleshooting
DVI-OPT-TX220-Pro, DVI-OPT-RX220-Pro User’s Manual 9. Troubleshooting 9.1. Picture is not displayed or distorted Usually, if the system seems not to transport the DVI signal as expected, the best strategy for troubleshooting is to check the signal integrity through the whole signal chain starting from the source side and moving forward to the receiver end. - Page 52 Step 5. Check the signal at the Local Monitor Output Check if there’s an outgoing signal on the LOCAL MONITOR OUTPUT connector of the transmitter. The input signal is always routed to the output connector. If there is a signal on the LOCAL MONITOR OUTPUT connector, then the problem is not EDID related.
-
Page 53: Specifications
DVI-OPT-TX220-Pro, DVI-OPT-RX220-Pro User’s Manual 10. Specifications General Compliance ....................... CE EMI/EMC ............... EN 55103-1, EN 55103-2 Safety ..................EN 60065 Class I Warranty ....................3 years Operating temperature ..........0 to +55°C (+32 to +122°F) Operating humidity ........... 10% to 90%, noncondensing Cooling .................. - Page 54 EDID memory (TX220) ....yes, 50 factory preset, 49 user programmable EDID support (TX220) ..........256 byte extended EDID v1.3 HDCP compliant ....................No Optical Fiber type ..............50/125 SC Multimode fiber Laser wavelengths ........4ch. CWDM: 778; 800; 825; 850 nm Laser class specification ................
-
Page 55: Mechanical Drawings
DVI-OPT-TX220-Pro, DVI-OPT-RX220-Pro User’s Manual 10.1. Mechanical drawings Info: DVI-OPT-TX220-pro can be seen on the pictures; the external dimensions and the fixing holes of all units are the same. Front view Top view Rear view Section 10. Specifications Page 55 / 57... - Page 56 Left view M3 thread Bottom view 178,5 21,7 M3 thread Page 56 / 57 Section 10. Specifications...
-
Page 57: Version Applicability
Lightware Visual Engineering warrants this product against defects in materials and workmanship for a period of three years from the date of purchase. The customer shall pay shipping charges when unit is returned for repair. Lightware will cover shipping charges for return shipments to customers.
