Sercos Gateway
During the mounting, installation and usage of the SafeLogic
compact Sercos Gateway, comply with the standards and
directives applicable in your country
The national and international rules and regulations apply to the
installation and use as well as commissioning and periodic
technical inspection of the modular SafeLogic compact safety
control, in particular:
– The low voltage directive 2014/35/EU
– Machine directive 2006/42/EC
– EMC directive 2014/30/EU
– Provision and use of work equipment directive 2009/104/EC
– The accident prevention regulations and safety rules
Only skilled personnel can execute the tests.
These operating instructions do not provide instructions for
operating the machine in which the safety controller is, or will be,
integrated. The operating instructions of the machine contains the
information.
WARNING
The SafeLogic compact system meets the prerequisites for class A (industrial
applications) according to the "emission" standard. The SafeLogic compact
system is thus only intended for use in an industrial environment.

4.1 UL/CSA applications

To be used in a Pollution Degree 2 environment only.
Use 60°C/75°C conductors. The max. operating ambient temperature is 55°C.
For UL applications the device must be used with a Class 2 power supply or
Class 2 transformer in accordance with UL1310 or UL1585.
The power supply of the SafeLogic compact Sercos Gateway has to be
executed by a power supply unit with protective separation, protected by a
fuse according to UL 248 with max. 100 V. V corresponds to the DC supply
voltage with a max. of 42.4 V DC. The UL 508 requirements are thus complied
with.
The safety functions are not evaluated by UL. The approval is granted
according to UL 508, general applications.
DOK-CONTRL -SLC*GW*GS3S-IT03-EN-P
Only use the SafeLogic compact system in an
industrial environment!
Bosch Rexroth AG
Intended use
7/31
