Tamper Switch Module - 2N IP Style Installation Manual

• The inputs / outputs are addressed as follows: <module_name>.<input/output_name>,
e.g. module5.relay1. The module name is configured in the Module name parameter in the
Hardware / Extenders menu.
RELAY1
RELAY2
IN1
IN2
TAMPER
Tamper Switch Module
The Tamper switch module (Part No. 9155038) is one of the 2N IP Verso system elements and
helps secure the system against tampering.
• The module contains two switches, which open whenever the front frame is removed:
• One switch leads directly to the terminal board and is connected to an external
security exchange (32 V DC / 50 mA max).
• In coordination with the I/O module (9155034) or Wiegand module (9155037), the
other switch can be used for initiating alarm via the Automation interface in the
2N IP Style configuration.
• This module is not connected to the bus.

Caution
• Remember to purchase the I/O module, Part No. 9155034, along with the tamper
switch.
RELAY1 terminals with accessible 30 V / 1 A AC/DC NO/NC contact
RELAY2 terminals with accessible 30 V / 1 A AC/DC NO/NC contact
IN1 terminals for input in passive/ active mode (−30 V to +30 V
DC)
OFF = open OR U
IN
ON = closed contact OR U
IN2 terminals for input in passive/active mode (−30 V to +30 V DC)
OFF = open OR U
IN
ON = closed contact OR U
Tamper switch (9155038) input
Installation Manual 2N® IP Style
> 1.5 V
< 1.5 V
IN
> 1.5 V
< 1.5 V
IN
68 / 90
