LAN BOOT
LAN connection restart button
BUTTON
SD CARD
SD card slot
CONTROL
Factory reset button
BUTTON
POWER LED
Device status LED
LAN LED
LAN connection status LED
VBUS
Bus connector
SHIELD
Grounding terminal
IN1, IN2, IN3
Input terminals in passive / active mode (−30 V to +30 V DC)
OFF = open contact OR U
ON = closed contact OR U
TAMPER
Security system connecting terminals (on the back side above the connectors)
SWITCH
OUT
12 V / 0.6 A DC active output
RELAY
30 V / 1 A AC/DC NO/NC contact terminals. Used for connection of non-critical
devices only (lights, e.g.).
POWER 12
External 12 V / 4 A DC power supply terminals
V / 4 A
LAN
Optionally PoE+ 802.3at for device LAN connection
connector
Tamper
Switch detecting unauthorized device opening
Switch
Legend to the figure
> 1.5 V
IN
< 1.5 V
IN
