5
In the same way as step 4, enter
the global variables as tags in
ascending order of IN No. listed
in 6.3. Tag Sets.
6
Click the Output Tab in the Tag
Sets.
Right-click on a space on the
Output Tab Page, and select
Create New Tag Set from the
menu.
7
A new tag set name can be
entered. In the same way as
step 3, enter EIP002_OUT.
8
In the same way as step 4, enter
the global variables as tags,
which are listed in 6.3. Tag Sets.
9
Check that the number of Tag
Sets is 2 and that the number of
Tags is the total number of set
global variables (e.g. 7).
7．EtherNet/IP Connection Procedure
30
