Output area (Controller to Indicator)
Name
EIP002_Settings1_OUT
EIP002_Settings2_OUT
Details of output data
Control signal 1
B7 B6
Stop Start
B15 B14
- -
Control signal 2
B7 B6
Span Linearization
correction cal. 3
B15 B14
- -
Additional Information
For details on setting the data in tag data links for the Indicator, refer to 7-4. Cyclic
communication of the FC400-EIP OPERATION MANUAL (18AUG2021).
Additional Information
With Sysmac Studio, two methods can be used to specify an array for a data type.
After specifying, (1) is converted to (2), and the data type is always displayed as (2).
(1) BYTE[2] / (2) ARRAY[0..2] OF BYTE
In this guide, the data type is simplified by displaying BYTE[2].
(The example above means a WORD data type with two array elements.)
Network
Data type
publish
WORD Output
WORD Output
B5 B4
G/N HOLD
switch
B13 B12
- -
B5
Linearization Linearization
cal. 2 cal. 1
B13 B12
-
6．EtherNet/IP Settings
Indicator
data assignment
m+0 Control signal 1
m+1 Control signal 2
B3 B2
TARE TARE DZ
reset reset
B11 B10
- - Auto
adjustment
filter
B4 B3 B2
Span Zero
cal. cal.
B11 B10
- - -
Data size
(byte)
2
2
B1 B0
DZ
B9 B8
Comparison
inhibit
B1 B0
Equiv. Equiv.
span zero
cal. cal.
B9 B8
- -
10
