5
In the same way as step 3,
select Create New from the
menu, and in the same way as
step 2, enter the following data.
- Name:
EIP002_Tare_Amount_IN
Data Type: DINT
Network Publish: Input
- Name: EIP002_Status1_IN
Data Type: DWORD
Network Publish: Input
- Name: EIP002_Status2_IN
Data Type: DWORD
Network Publish: Input
- Name: EIP002_Setting1_OUT
Data Type: WORD
Network Publish: Output
- Name: EIP002_Setting2_OUT
Data Type: WORD
Network Publish: Output
6
Double-click Task Settings
under Configurations and
Setup in the Multiview Explorer.
The Task Settings Tab Page
appears in the Edit Pane.
Click the VAR Button.
