4
To check communication, switch
Main Display of Indicator from
gross to net weight display in
the following way.
Enter 0000 0000 0010 0000 in
the Modify Column for
EIP002_Settings1_OUT.
The online value of Bit 5 of
EIP002_Settings1_OUT
changes to 1.
The online value of Bit 6 of
EIP002_Status2_IN changes to
1. It indicates net weight display.
5
Main Display of Indicator is
changed from gross to net
weight display and shows NET
(net weight display).
Main Display of Indicator shows
0.25.
*The net weight value shown on
Main Display varies depending
on the usage conditions of
Indicator.
7．EtherNet/IP Connection Procedure
41
