Specifications - Altronix eFlow104NA8 Series Installation Manual

Inputs:
eFlow104NB:
• 120VAC, 60Hz, 4.5A.
ACMS8/ACMS8CB:
• Eight (8) trigger inputs:
a) Normally open (NO) inputs (dry contacts).
b) Normally closed (NC) inputs (dry contacts).
c) Open collector sink inputs.
d) Wet Input (5VDC - 24VDC) with 10K resistor
e) Any combination of the above.
Outputs:
Power:
• 12VDC or 5VDC up to 6A, 24VDC up to 10A
(240W total power).
• Auxiliary Class 2 power-limited output
rated @ 1A (unswitched).
• Overvoltage protection.
ACMS8:
• Fuse protected outputs rated @ 2.5A per output,
non power-limited. Total output 6A max.
Do not exceed the individual power supply ratings.
ACMS8CB:
• PTC protected outputs rated @ 2A per output,
Class 2 power-limited. Total output 6A max.
Do not exceed the individual power supply ratings.
• Eight (8) selectable independently controlled
outputs or eight (8) indepently controlled
Form "C" relay outputs (see below for ratings):
a) Fail-Safe and/or Fail-Secure power outputs.
b) Form "C" relays rated @ 2.5A. 12, 24VDC,
0.6 Power Factor (ACMS8 only).
c) Auxiliary power outputs (unswitched).
d) Any combination of the above.
• Individual outputs may be set to OFF position for
servicing (output jumper set to middle position).
Does not apply to Dry Contact applications.
• Any of the eight (8) fuse/PTC protected power
outputs are selectable to follow power Input 1 or
Input 2. Output voltage of each output is the same
as the input voltage of the input selected.
• Surge suppression.
Fuse/PTC Ratings:
eFlow104NB:
- Input fuse is rated 6.3A/250V.
- Battery fuse rated 15A/32V.
ACMS8:
- Main input fuse is rated 15A/32V.
- Output fuses are rated 3A/32V.
ACMS8CB:
- Main input PTC is rated 9A.
- Output PTCs are rated 2A.
eFlow104NKA8(D) Installation Guide

Specifications:

Battery Backup (eFlow104NB):
• Built-in charger for sealed lead acid or
gel type batteries.
• Maximum charge current 1.54A.
• Automatic switch over to stand-by battery when
AC fails.
Transfer to stand-by battery power is instantaneous
with no interruption.
Supervision (eFlow104NB):
• AC fail supervision (form "C" contacts).
• Battery fail & presence supervision
(form "C" contacts).
• Low power shutdown. Shuts down DC output
terminals if battery voltage drops below 71-73% for
12V units and 70-75% for 24V units (depending on
the power supply). Prevents deep battery discharge.
Fire Alarm Disconnect:
eFlow104NB:
• Supervised Fire Alarm disconnect (latching or
non-latching) 10K EOL resistor. Operates on a
normally open (NO) or normally closed (NC) trigger.
ACMS8(CB):
• Fire Alarm disconnect (latching or non-latching) is
individually selectable for any or all of the
eight (8) outputs.
Fire Alarm disconnect input options:
a) Normally open [NO] or normally closed [NC]
• FACP input WET is rated 5-30VDC 7mA.
• FACP input EOL requires 10K end of line resistor.
• FACP output relay [NC]:
Either Dry 1A/28VDC, 0.6 Power Factor or
10K resistance with [EOL JMP] intact.
Visual Indicators:
eFlow104NB:
• Green AC LED:
• Red DC LED:
ACMS8(CB):
• Red LEDs:
• Blue LED:
• Individual
Voltage LEDs:
Environmental:
• Operating temperature: 0ºC to 49ºC ambient.
• Humidity: 20 to 85%, non-condensing.
Enclosure Dimensions (approximate H x W x D):
15.5" x 12" x 4.5"
(393.7mm x 304.8mm x 114.3mm).
dry contact input. Polarity reversal input from
FACP signaling circuit.
Indicates 120VAC present.
Indicates DC output.
Indicate outputs are triggered.
Indicates FACP disconnect
is triggered.
Indicate 12VDC (Green) or
24VDC (Red).
